Dual Cooling and Dual Guard
Two independent systems ensure uninterrupted operation, even if one fails; Dual systems reduce
individual load, extending overall lifespan
Super and Even Cooling
» 180 minutes rapid Cooling (25°C to -81°C)
» ±3 Uniformity
FLEX-VOLT® (115-240~V)
Stable operation at 100-240-V, 50/60Hz.
Additional Features
» 10.1 inch LCD Touch Display
» 304 SS vs PCM
» 220V 10A Plug (10A VS 15A)
» Ingenious Handle Design
» Li-ion vs Lead-Acid (Maintenance-Free)
» Five-Layer Silicone Seal
» Anti-Condensation (80% Humidity)
Default Set Point-81°C
Power 100V-240~V /50Hz/60Hz
Current 14A (at 100V) ,6.5A(at 240V)
Power Cord Length 1.7m
Certification CE
Door type Solid door
Application Environment Non-corrosive, non-flammable, non-explosive
Ambient Operating Temperature 10°C~32°C
Refrigeration System Dual Inverter cooling
Compressor Hermetic, variable speed
Expansion Device Capillary tube
Evaporator Type Built-in
Defrost Method Manual defrosting
Refrigerant Mix refrigerant
Exterior Dimensions WxDxH (mm) 1030*995*1980 mm
Access Port 2 Access Port- for external monitoring
probe(s) (25 mm diameter)
Shelf 3 | 87 kg max capacity
Wheels 4 Swivel Casters + 2 Leveling Feet
Display Screen 10.1“LCD Touch screen
Controller Type Microprocessor
Security Lockable door, password protected settings
Control Sensor PT1000, stainless steel
Communication Ports USB, Remote alarm contacts
Power Failure Alarm Yes
High/Low Alarms Yes, fully adjustable
Door Ajar Alarm Yes
Download Yes, via USB, PDF
Temperature Log Yes, download via USB
Battery Back-up Yes, 17 hour display and alarm back-up
Rechargeable 12V, li-ion battery
