Compact laboratory chiller sklc

air-cooled

The compact refrigeration units of the sklc series are energy-efficient chillers (refrigeration units) with an integrated air-cooled condenser. Thanks to their high level of reliability, they are particularly suitable for industrial cooling processes. Shell-and-tube evaporators ensure a high level of operational reliability and optimum heat transfer to the refrigeration circuit. The integrated energy-saving module and the high-quality electronic expansion valve, which ensures a gliding condensation control, increase the efficiency of the system even further. With an optimised mode of operation, the users can realise cost savings of up to 35% compared to conventional chillers. If already existing chillers are replaced, cost savings of up to 60% are possible. Benefits at a glance Compact design Temperature range from +4°C to +25°C Optimised EER values Stepless power control Gliding condensation control Operating cost reduction between 35% and 60% Features and product characteristics Compact air-cooled chillers with an integrated condenser Units equipped with screw compressors and stepless power control Option: Compact screw compressor with an integrated variable frequency drive Option: HFO refrigerant R1234ze [GWP = 7]
