W = 680 mm
D = 580 mm
H = 1430 mm
W = 520 mm
D = 451 mm
H = 777 mm
Capacity: 182 l
Temperature range: -9,9°C to 70°C
galvanised steel sheet, epoxy-resin-coated, RAL. 7035. Unit on four castors, lockable.
Made of high grade stainless steel. Cleaning friendly by rounded corners, slippery surface in the interior, meets highest hygiene requirements
The thermo-jacket circulation system ensures even temperature and humidity distribution in the chamber and prevents drying of the samples. The air flow is outside the work space. The circulation fan stops about 40 seconds after opening the door, though who the internal temperature is near the outside temperature. Simply removing the inner casing for intensive cleaning.
Double-walled insulation door, hinged on the right-hand side. Magnetic, all-round sealing strip, resistant to laboratory cleaning agents.
with door lock Inspection window in the front door, triple glazed with cover
Dim: W: 32 cm, H: 77 cm – see photo
Standard: 3 pcs. perforated stainless steel shelves (max. 14 pcs.) Max. load per shelf: 20 kg in case of constant distribution – total load: 120 kg Shelf dimension: W = 500 mm, D = 450 mm
Control and instrument panel,
located above the door incl. temperature controller with digital indication
with digital LCD-display. Entry of temperature and time with membrane keypad, readable on LCD-display.With serial interface RS 232C. Time values can be given in minutes from 1 to 999.
