Medical trolley Eolis®

hospitalmedicationmedicine distribution

Overview
Eolis® medication cart 1006.11M02, ISO 600x400 modular system, roller shutter version with removable ABS shutter (top→down). SKU: 1006.11M02.

Design & features

• Modular design with internal ABS rails compatible with ISO 600x400 accessories (drawers, bins, trays).
• Open-front unit, closed on five sides; closing by contiguous drawers or removable ABS roller shutter (top→down). Optional central locking.
• Frame: anodized aluminium and epoxy-coated steel; side and base panels in ABS, available in 8 colours. Enclosing ABS bumper in grey.
• Worktop: ABS/PMMA (beige) with raised edges — 705 x 415 mm (drawer configuration) or 705 x 480 mm (roller shutter configuration).
• Standard equipment: 1 ergonomic push handle and 2 height-adjustable standardized rails (one per side).
• Castors Ø125 mm, 2 braked; polyamide fork; grey non-marking rubber tread; stainless steel ball bearings; fitted with cable guards.

Use & modularity
Modular solution for secure storage and point-of-care transport of medicines in clinical environments. Compatible with a wide range of ISO 600x400 internal equipment. Options include contiguous drawers, removable roller shutter and central locking to adapt access control and internal layout to hospital workflows.

Technical specifications

• Accessory format: ISO 600x400.
• Reference / SKU: 1006.11M02.
• Closure: removable ABS roller shutter (top→down) or contiguous drawers.
• Frame: anodized aluminium + epoxy-coated steel.
• Panels: ABS (sides and base), 8 colours available.
• Bumper: ABS (grey).
• Worktop: ABS/PMMA beige — 705 x 415 mm (drawers) / 705 x 480 mm (roller shutter).
• Handle: 1 ergonomic push handle.
• Rails: 2 standardized rails, height-adjustable.
• Wheels: Ø125 mm swivel castors, 2 braked; polyamide fork; grey non-marking rubber tread; stainless steel ball bearings; cable guards.
• Options: central locking (optional), choice of internal accessories (drawers, bins, trays).
