Membrane ultrafilter Vivafree™ 2

for serumfor protein solutionsfor liquids

Product overview
Vivafree™ 2 centrifugal ultrafiltration devices are intended for in vitro diagnostic (IVD) use to rapidly separate free drugs and hormones from serum proteins for therapeutic drug monitoring and clinical hormone assays. They accept up to 2 ml starting volume and deliver rapid separations (typical 20–60 minutes) with high recovery and reproducible results. Devices are compatible with fixed-angle and swing-bucket rotors and are designed to fit 15 ml (17 mm) conical-bottom tube cavities.

Clinical applications

• Separation of free hormones (testosterone, insulin, cortisol).
• Sample preparation for therapeutic drug monitoring (phenytoin, valproic acid, antibiotics, immunosuppressants).
• Protein removal prior to mass spectrometry analysis.
• Preparation of samples for drug-binding and free fraction studies.

Performance (examples)

• Vivafree™ 2 — 30,000 MWCO — Free Cortisol: 500 µl initial → 100 µl filtrate — 20 min @ 37 °C — 2,500 × g.
• Vivafree™ 2 — 30,000 MWCO — Free Phenytoin: 1,000 µl initial → 200 µl filtrate — 20 min @ 25 °C — 1,500 × g.
• Vivafree™ 2 — 30,000 MWCO — Free Testosterone: 300 µl initial → 100 µl filtrate — 20 min @ 37 °C — 4,500 × g.
• Vivafree™ 2 — 30,000 MWCO — Diluted Free Testosterone: 1,000 µl (diluted serum) → 500 µl filtrate — 60 min @ 25 °C — 4,500 × g.

Ordering / Packaging & Pricing (examples shown)

• VFR02H22 — 30,000 MWCO, Hydrosart® membrane, 100 per pack — Price: $535.00
• VFR02H23 — 30,000 MWCO, Hydrosart® membrane, 500 per pack — Price: $2,300.00

Technical specifications

• Maximum starting volume: 2 ml (fixed-angle and swing-bucket rotors).
• Total length: 125 mm; Width: 16 mm; Active membrane area: 0.95 cm².
• Hold-up volume (membrane and support): <10 µl; Dead stop volume (fixed-angle, 25°): 55 µl; No dead stop in swing-bucket rotor.
• Body material: Polycarbonate; Filtrate vessel, back spin vial and concentrator cap: Polypropylene; O-ring: Silicone.
• Membrane examples: Hydrosart® (30,000 MWCO) or Cellulose Triacetate (125,000 MWCO).
• Compatible rotor types: Fixed-angle or Swinging-bucket for 15 ml (17 mm) conical-bottom tube cavity (95 mm depth).
• Maximum centrifugal force: up to 5,000 × g (30,000 MWCO configurations); up to 2,500 × g (125,000 MWCO configurations).
