Medical device manufacturing tubing E-T-170077
Add to favorites
Compare this product
Characteristics
- Applications
- for medical device manufacturing
- External diameter
3.2 mm
(0.1 in)- Inner diameter
1.7 mm
(0.1 in)
Description
15 Metre coil (50 Feet) of Ether based UV Stabilized Blue Colour High-Flex 85A Polyurethane tube with an wall thickness of 0.76 mm (0.030") suitable for use with barb style fittings
Non-Wetted Materials
Polyurethane
Wetted Materials
Polyurethane
Cleanroom Manufactured
Uncontrolled environment
Temperature Range
-40°C – 74°C (-40°F – 165°F)
Working Pressure
3:1 Safety Factor
Operating Range at 25⁰C
Vacuum to 9.31 bar (135 psi) at 25°C (75°F)
Diameter Tolerance
±0.127 mm (±0.005")
Operating Range at 65⁰C
Vacuum to 3.79 bar (55 psi) at 65°C (150°F)
Item Weight
0.098Kg (98 gram)
ROHS Compliant
Yes
Regulatory Information
USP Class VI. NSF61, Meets UL94HB Testing requirements
CE Mark
No
REACH Compliant
Yes
