Vessel-sealing electrosurgical unit Shalya Easy+v

bipolar cuttingmonopolar coagulationmonopolar cutting

Product overview
Compact electrosurgical unit designed for a broad range of surgical specialties. Provides monopolar and bipolar modalities, vessel sealing up to 7 mm and user-programmable settings for procedure-specific control.

Applications

• Plastic surgery
• Neurosurgery
• ENT
• Spine surgery
• Ophthalmic procedures
• Laparoscopic and endoscopic surgery
• Gastrointestinal, general and oncologic surgery
• Orthopedics, urology and gynecology

Key features

• 7-segment display: Clear numeric readout for selected settings and power.
• 300 W maximum power: Support for a variety of monopolar and bipolar procedures.
• 6SENSE Technology: Tissue feedback technology to maintain set power across varying tissue impedances.
• PREM: Patient Return Electrode Monitoring with alarm to reduce risk of return-site burns.
• Vessel Sealing Mode: Reliable sealing for vessels up to 7 mm with reusable open, hand/foot and laparoscopic attachments.
• Bipolar Scalpel Mode: Bipolar cutting/coagulation via foot-activated bipolar scalpel.
• Randomized SPRAY Coag: Even superficial coagulation over larger areas.
• BiCoag Alarm: Audio confirmation at bipolar coagulation completion to reduce charring and sticking.
• Auto Stops: Automatic cessation of energy with audio indication at sealing cycle end.
• User Programmable: Ten user-settable surgical programs for rapid recall after power ON.
• Self Diagnosis: Built-in diagnostics with error code display for safe operation.
• Optional pulse/Endo Cut: Tissue-feedback pulsed cutting for polypectomy and papillotomy.
• Optional remote power settings: Change mode and power from the sterile field via handswitch pencil.
• Foot switch: Toggle between modes; wireless option available.
• Optional Time Out function: Automatic HF output stop on prolonged unintended activation.

Technical specifications

• Display: 7-segment display
• Maximum Power: 300 W
• User Programs: 10 user-settable surgical programs
• Tissue Feedback: 6SENSE Tissue Feedback Technology
• Return Electrode Monitoring: PREM with alarm
• Vessel Sealing: Sealing capability up to 7 mm (open, hand/foot & laparoscopic attachments)
• Modes: Monopolar cut/coag, Bipolar scalpel mode, Vessel sealing mode, Randomized spray coagulation
• Optional Features: Pulse/Endo Cut, Remote power settings, Argon Beam Coagulation, Ultrasonic Aspirator, Smoke Evacuator, Suction Irrigation module, Time Out function
• Safety: Self-diagnosis with error code display; BiCoag alarm
