Overview
Our Intelligent Imaging Platform integrates CBCT imaging, AI analysis and clinical workflows to convert complex 3D datasets into clear, actionable clinical information. The solution supports faster case review, consistent decision support and more efficient time allocation for patient care.

Key Benefits

• Intelligent Automation — Reduce repetitive tasks with AI-driven reconstruction, detection and measurement to accelerate daily workflows.
• Clear Clinical Insight — Convert complex 3D data into intuitive, actionable views via synchronized multi‑planar and 3D visualization.
• One Connected Workflow — Review images, plan implants, analyze orthodontic cases and assess TMJ and airway within a unified platform.
• Confident Decision Support — Fast, reliable AI analysis to support reproducible clinical decisions.

Intuitive MPR (Multi-Planar Reconstruction)
Navigate complex 3D anatomy with an MPR workspace designed to simplify interpretation and improve efficiency.

• Instant Multi-Planar Navigation — Click any point in the 3D view to synchronize coronal, sagittal and axial planes for rapid spatial orientation.
• One-Click Spine Removal — Automatically remove cervical spine structures from 3D reconstructions to reveal unobstructed dental arch views.

3D Rendering Modes
Switch instantly between seven rendering presets tailored to clinical needs to highlight bone, dentition, soft tissue or airway structures.

• Dentition Mode
• Bone Mode
• Dentition & Soft Tissue Mode
• Bone & Soft Tissue Mode
• Soft Tissue Mode 1
• Soft Tissue Mode 2
• Airway Mode

Intelligent Panoramic Reconstruction
Automatically generate optimized panoramic images from CBCT data. Algorithms determine the optimal curve and layer thickness, removing the need for manual adjustments for medium and large FOV scans.

Automatic Mandibular Nerve Mapping
Automatically identify and trace the mandibular canal from CBCT data to support safer implant planning and streamline risk assessment.

Intuitive Virtual Implant Planning
Plan implant placement directly in panoramic or MPR views using the integrated implant library. Measure anatomy, select implants and adjust position, angulation, depth and diameter via a three-step workflow (Measure → Select Implant → Adjust Placement).

Comprehensive Implant Validation
Validate implant plans by assessing positioning, angulation, adjacent anatomy and bone density. Visual bone density analysis supports refined planning and clearer patient communication.

TMJ Analysis
One-click TMJ localization enables evaluation of condylar morphology, position and relation to the glenoid fossa from any angle, with synchronized 2D sectional views and 3D reconstructions. Available for 20 × 18 cm large FOV scans.

Cephalometric Analysis
Advanced AI tools support cephalometric analysis for orthodontic and orthognathic planning. Not available for 8 × 8 cm or 4 × 4 cm modes; available in 20 × 18 cm mode.

Airway Analysis
One-click airway identification and segmentation (nasopharyngeal, retropalatal, retroglossal). The software locates the narrowest region and calculates cross-sectional areas across segments to provide quantitative metrics for airway assessment and OSA screening. Enabled by default in 20 × 18 cm mode and optional in 17 × 10.5 cm mode.

Orthodontic Suite
An integrated orthodontic workspace combining automation, treatment analysis and professional reporting.

• Automatic Landmark Detection — Identify hundreds of cephalometric landmarks automatically.
• Analysis Selection — Generate measurements with established analyses such as Steiner, Tweed and WCSS; clinicians can review and edit results.
• Treatment Superimposition — Compare images from different treatment stages to visualize tooth movement and skeletal changes.
• Custom Reference Values — Configure reference values for personalized analyses.
• Professional Orthodontic Reports — Generate reports in one click; export as PDF or image files for documentation and multidisciplinary consultation.

Imaging Reports
Professional, fully customizable reporting for panoramic, cephalometric and TMJ exams with a template editor for layouts, typography and comments.

Technical specifications

• Product name: AI for Dentistry intelligent imaging platform
• Integrates CBCT imaging, AI-assisted analysis, implant planning, orthodontics, TMJ and airway assessment in a single workflow
• Automatic mandibular canal mapping (AI-driven)
• One-click spine removal for 3D reconstructions
• Seven 3D rendering presets: Dentition, Bone, Dentition & Soft Tissue, Bone & Soft Tissue, Soft Tissue Mode 1, Soft Tissue Mode 2, Airway Mode
• Panoramic reconstruction: automatic curve and layer thickness optimization; available for medium and large FOV scans
• Implant planning: integrated implant library; measure and adjust implant position, angulation, depth and diameter
• Implant validation: assessment of positioning, angulation and bone density
• TMJ analysis: available for 20 × 18 cm large FOV (2D and 3D views)
• Cephalometric analysis: not available for 8 × 8 cm or 4 × 4 cm; available in 20 × 18 cm mode
• Airway analysis: enabled by default in 20 × 18 cm; optional in 17 × 10.5 cm mode; provides cross-sectional area calculations and segmentation
• Orthodontic tools: automatic landmark detection, support for Steiner / Tweed / WCSS analyses, treatment superimposition, custom reference values
• Report export formats: PDF and image
• Designed to improve clinical efficiency, standardize image quality and support consistent decision-making
