血管病変用レーザー LASEVIA

外陰膣形成用脂肪分解用体のバイオスティミュレーション用

Overview
LASEVIA is a multi-wavelength semiconductor (diode) laser platform combining up to five diode wavelengths in one portable console. Configurations support aesthetic, vascular, surgical and therapeutic indications across eight clinical specialties, delivering up to 30 W+ peak output from a Class 4 device with an 11.6" Android smart touchscreen.

Wavelength architecture

• Available wavelengths: 450 / 635 / 980 / 1470 / 1940 nm (configuration-dependent)
• Each diode is matched to a specific chromophore: water, haemoglobin, lipid or melanin; independently switchable

Factory configurations (table)
Configuration A — 1940 · 1470 · 980 · 635
1940 nm — 10 W
1470 nm — 15 W
980 nm — 20 W
635 nm — 500 mW
Fiber core 200 µm · Endolifting · Lipolysis · Vascular

Configuration B — 1470 · 980 · 450 · 635
1470 nm — 15 W
980 nm — 30 W
450 nm — 8 W
635 nm — 2 W
Fiber core 200 / 400 µm · Therapy · Proctology · LVR

Key emission & delivery features

• Emission modes: CW · single pulse · repeat pulse
• Pulse width: 25 µs – 10 s
• Repetition rate: 0.05 Hz – 50 kHz
• Fiber interface: SMA905 universal port (accepts contact fibers 200 / 400 / 600 / 1000 µm and non-contact tips)
• Universal SMA905 delivery enables fast handpiece swapping

Clinical specialties & applications

• Endolifting — deep 1940 nm fractional fiber for non-surgical lifting (face, neck, body)
• Lipolysis — ring-light fiber emulsifies adipose via micro-cannulas for mini-invasive body contouring
• Spider vein & vascular — transdermal and endovenous coagulation of telangiectasia and varicose veins
• Therapy · HILT Class IV — deep-tissue photobiomodulation for pain, inflammation and tissue repair
• LVR (vaginal rejuvenation) — non-ablative 635 nm intimate-health protocols
• Proctology — fiber-delivered coagulation for haemorrhoids and fistulas
• EVLT — endovenous laser ablation using 1470 / 1940 nm for vein sealing
• ENT — 450 nm blue diode for minimally invasive soft-tissue ENT surgery

Device & usability

• 11.6" Android smart touchscreen with touch presets, real-time energy readouts and one-tap protocol recall
• Portable console: 15 kg with single-handle carry frame
• Emergency laser stop (mushroom switch) and mechanical safety shutter
• Multi-mode emission tuned per indication (CW, single-pulse, repeat-pulse)

Delivery ecosystem — handpieces, fibers & accessories

• Handpiece sets: Basic Handpiece Set (endolifting & lipolysis), Advanced Liposuction Set, SUPERSCAN Focus Set (spider vein & fractional), LVR Handpiece Set, PM5 Therapy Set, disposable LVR and disposable surgical sets
• Fibers: High-Power Fiber (SMA905), Bare Fiber (direct contact), Polyimide Fiber, Radial Fiber (360° radial emission), Hemorrhoid Fiber (typically 600 µm)
• Accessories: Laser safety goggles, foot switch, fiber cutter, fiber stripper, optic connector cleaner

Certifications & safety

• Device class: Class 4
• Certifications: CE · MDSAP · ISO 13485 · FDA-cleared therapeutic-laser instrument technology

Notes
Maximum output and precise wavelength/power mix are configuration-dependent; multiple factory configurations are available to match clinical indications.

Caractéristiques / spécifications techniques

• Laser type: Multi-wavelength semiconductor (diode) laser platform
• Wavelengths: 450 / 635 / 980 / 1470 / 1940 nm (configuration dependent)
• Maximum output: Up to 30 W+
• Emission modes: CW · single pulse · repeat pulse
• Pulse width: 25 µs – 10 s
• Repetition rate: 0.05 Hz – 50 kHz
• Delivery system: SMA905 fiber interface · contact fibers 200 / 400 / 600 / 1000 µm · non-contact tips
• Interface: 11.6" Android smart touchscreen
• Safety: Emergency laser stop · mechanical safety shutter · Class 4
• Power supply: 100 – 240 V, 50 – 60 Hz, 350 VA
• Weight: 15 kg (portable console)
• Certification: CE · MDSAP · ISO 13485 · FDA-cleared therapeutic laser
