Doctor's office stool ak446

operating roommedicalheight-adjustable

Product description
The ak446 hydraulic doctor’s stool is fitted with a round seat and a stable five-arm castor base equipped with high-quality castors for mobility. Height is adjusted using a foot-operated hydraulic pump column whose pump handle can swivel 360°. The stool is available with or without backrest and armrests; armrests are easily and flexibly adjustable. Horizontally movable armrest holders allow easy positioning of the armrests relative to the elbows. Optionally the stool can be fitted with pre-shaped multidirectional multi-joint armrests for finer forearm/hand support during procedures. AKRUS upholstery is manufactured to high standards, is comfortable and easy to clean. Various upholstery colours are available to match hospital or practice environments. The ak446 hydraulic stool is delivered fully assembled and is built from high-quality components for many years of reliable use when used as intended. Authorized medical-technology dealers are available for service requests.

Application areas

• Ophthalmology
• ENT, OMF
• General, plastic & aesthetic surgery

Upholstery colours

• Combra White
• Cream
• Sand
• Pearl
• Lilac
• Blue-grey
• Cornflower
• Midnight Blue
• Yellow
• Orange
• Red
• Opera
• Mint
• Turquoise
• Anthracite
• Black

Technical specifications

• Base diameter: 600 mm
• Castor diameter: 50 mm
• Height adjustment: 530 - 720 mm
• Seat surface: 430 - 340 mm
• Seat cushion thickness: 80 mm
• Armrest height adjustment: 140 - 290 mm
• Maximum permitted person weight: 135 kg

Environmental conditions — Application

• Air temperature: +10 °C to +40 °C
• Relative humidity: max. 50% non-condensing
• Air pressure: 700 - 1060 hPa

Storage without original packaging

• Air temperature: -10 °C to +55 °C
• Relative humidity: 10% to 95% non-condensing
• Air pressure: 700 - 1060 hPa

Storage & transportation in original packaging

• Air temperature: -40 °C to +70 °C
• Relative humidity: 10% to 95% non-condensing
• Air pressure: 700 - 1060 hPa

Downloads / Documents
Product information, declaration of conformity and user manual are available for model series ak445 / ak446 / ak447.
