Medical gas pressure reducer station AM-RS-400

oxygenairmedical

Overview
Dual-line medical gas pressure regulating station with integrated LCD alarm for stable secondary pressure control and continuous monitoring of medical gas supply. Designed for installation on medical gas distribution networks to manage automatic switching between duty and standby sources and to provide audible and visual alarm notification.

Product detail
Amcaremed dual-line regulating station uses a single-stage pressure reduction design to maintain a steady outlet pressure suitable for downstream medical gas pipelines. The integrated LCD alarm module displays real-time pressure values and triggers audible and visual alerts on pressure deviation or source failure. Positive-pressure gases (oxygen, medical air) are fitted with pressure regulators; vacuum sources are monitored directly without pressure reduction. The compact wall-mounted enclosure facilitates installation and maintenance.

Features

• Single-stage pressure reduction for stable outlet pressure
• Integrated LCD digital alarm with audible and visual alerts
• Transparent viewing window for component inspection
• Flow capacity: 30 m³/h (larger capacities available)
• Supports simultaneous connection of multiple gas sources
• Dual-line configuration: one duty line and one standby line
• Input pressure range: 8–11 bar; Output pressure range: 3–5 bar
• Compact wall-mounted design for hospital installations

Technical specifications

• Design: Single-stage pressure reduction
• Alarm: Integrated LCD digital alarm module with audible and visual functions
• Viewing: Transparent viewing window
• Flow capacity: 30 m³/h (options for larger capacities)
• Gas source support: Simultaneous connection of multiple gas sources
• Configuration: Dual-line (duty + standby)
• Input pressure: 8–11 bar
• Output pressure: 3–5 bar
• Installation: Compact wall-mounted unit
