Articulated support arm SKYDOQ®

height-adjustablepositioningswivel

The Ceiling Fixing SKYDOQ® is the perfect solution to support operation lights and flat screen monitors in an OR environment. The intelligent construction made of aluminium and the slim product structure will result in short delivery times and short time installations on site. The seamless welding construction is designed to support up to 24 kg load on the extension arms. Adjustable stoppers at each extension arm simplifies the assembly of hard wired cable solutions. Product Information Description - Data Material - aluminium Versions - Single-, Double- and Triple Arm Arm lengths - 775, 925 und 1,075mm and hybrid length up to 1,550mm Load capacity - 1-arm = max. 24kg 2-arm = max. 48kg 3-arm = max. 56kg Ceiling flange - Star flange with 270mm hole pattern Electric - 3-pole or 9-pole commutators Ceiling cover - Divisible, 590mm diameter, 120mm height Stoppers - Optional, in 60° steps adjustable Colour - RAL 9010 texture Scope of supply - Flange, Ceiling cover, Drop tube, Extension Arms, Electric Shipping - All-in-one on an Euro-pallet (1,200x800mm)
