Skin rejuvenation laser VF6

dentalENT surgeryCO2

Product overview
Fractional CO2 laser system designed for skin whitening, acne spot treatment, scar and stretch mark reduction, vaginal tightening and a broad range of dermatological and aesthetic procedures. The VF6 uses a 10.6µm fractional CO2 beam to create microscopic treatment zones that stimulate collagen remodelling and controlled skin resurfacing while preserving adjacent tissue for faster recovery.

How it works
The fractional CO2 system divides the laser output into numerous micro‑beamlets to generate discrete microthermal treatment zones. Energy penetrates selectively into damaged fractional areas, promoting rapid healing of untreated surrounding skin. The controlled micro‑injury triggers collagen synthesis and epidermal renewal, improving texture and appearance.

Key features

• Fractional beam delivery creating localized microthermal zones.
• 10.6µm CO2 wavelength suitable for ablative resurfacing therapies.
• USA COHERENT RF metal laser tube with optional glass tube for consistent long‑term output.
• Interchangeable scanning heads: fractional, ultrapulse cutting, gynecology, ENT, dental and andrology heads for extended clinical indications.
• Integrated smoke evacuation system combining suction and exhaust for immediate plume removal.
• Multiple scan shapes (Square, Triangle, Round, Rectangle, Line, Hexagon) with hollow‑center options.

Applications

• Skin renewal and resurfacing
• Tattoo and pigmented lesion removal (all colors)
• Wrinkle reduction
• Acne and scar treatment
• Benign neoplasm removal
• Pigment correction
• Telangiectasia treatment
• Photo‑damage recovery and skin rejuvenation
• Actinic keratoses
• Face lift, skin tightening and whitening procedures
• Earlobe procedures (ear piercing)

Warranty & services
Manufacturer provides a 3‑year free warranty, lifetime maintenance and after‑sales support. OEM/ODM services available for distributors. Training documentation includes user manual, maintenance manual and training CD guidance.

Specifications / Technical data

• Model: VF6
• Brand: VCA LASER
• Type: CO2
• Application: Salon / Clinic / Gynecology / Dental / Andrology
• Portable: Non‑portable
• Power output: 40W
• Laser wavelength: 10.6µm
• Laser tube type: USA COHERENT RF metal tube (option: glass tube)
• Laser energy: 1–40W / 10–1000 mJ, adjustable
• Display: 8.4 / 10.4 / 15 inch LCD real‑color touch screen
• Light conducting system: 7‑joint articulated arm
• Available treatment modes: Fractional / Ultrapulse / Gynecology / Dental / Andrology
• Scan pattern size: 0.1 × 0.1 mm — 20 × 20 mm
• Scan shapes: Square, Triangle, Round, Rectangle, Line, Hexagon (hollow‑center available)
• Scan modes: Random; Sequence
• Figure options: multiple geometric shapes; hollow center available
