Vial label M61 series

cryogenic

Product Overview
Nylon cloth (B-499) wrap-around labels conform to tightly curved surfaces such as vial tops and small tubes. Service temperature range: -40 to 90 °C (-40 to 193 °F). Designed for laboratory identification where cryogenic, autoclave or freezer conditions are required.

Key Features

• Printer Compatibility: BMP61
• Dimensions: 25.40 mm (W) x 12.70 mm (H) x 9.53 mm (Dia)
• Material: Nylon cloth (Brady B-499)
• Finish & Colour: White, Matt
• Adhesive: Permanent acrylic, aggressive
• Application(s): Laboratory labelling (vial tops, tubes, bottles)

Key Characteristics
Article Number: 150884
Order Reference: M61-120-499
Total Qty per Pack: 250 sets / box
Qty per Roll: 250
Minimum Order Quantity: 1
Recommended Ribbon Series: R4300, R6400 (e.g., M61-R4310)
Brand: Brady®
Country of Origin: Mexico

Dimensions
Size - Width (mm): 25.40 mm
Size - Height (mm): 12.70 mm
Size - Diameter (mm): 9.53 mm
Core - Diameter (mm): 25.40 mm
Vertical Repeat (mm): 28.58 mm
Vial/Tube Volume (ml): 1.2 mL
Web Width (mm): 46.05 mm

Material Characteristics
Brady Material No.: B-499
Material Properties: Autoclavable, Cryogenic storage, Halogen-free
Thickness (mm): 0.166 mm
Environment: Autoclave, Freezer, Liquid Nitrogen
Max. Service Temp. °C: 90 °C
Min. Service Temp. °C: -40 °C
Surface Compatibility: Smooth, textured/rough, highly textured or low surface energy surfaces
Resistance Properties: Abrasion-resistant, Chemical-resistant, Humidity-resistant, Low temperature-resistant, UV/weather-resistant

Product Features
Shape: Rectangle

Printing Specifications
Print Technology: Thermal transfer
SmartCell: Yes
Recommended Ribbon: M61-R4310 (R4300 / R6400 series)

Compatibility
Printer Compatibility: BMP61

Compliance
UNSPSC: 55121612
RoHS: Compliant with 2011/65/EU (with exemptions)
REACH SVHC Status: Does not contain SVHC (as declared)
Approvals: CSA accepted, UL recognised, Halogen-free (approvals apply to white material only)

Technical specifications

• SKU / Reference: M61-120-499
• Brady Material No.: B-499
• Quantity per pack: 250 sets / box
• Label dimensions: 25.40 mm x 12.70 mm (H); Diameter 9.53 mm
• Material thickness: 0.166 mm
• Temperature range: -40 °C to 90 °C
• Suitable environments: Autoclave, Cryogenic storage, Freezer, Liquid Nitrogen
• Printing: Thermal transfer (recommended ribbons: R4300/R6400)
• Resistance: Abrasion, chemicals, humidity, low temperature, UV, weather
