2-way infusion manifold RPB series

4-way3-way5-way

Description
Manifolds with 2 to 6 stopcocks and coextruded PE/PVC male–male extension lines for infusion applications. Coextruded PE/PVC limits interactions between medications and PVC, helping to preserve drug compatibility during administration. The table below lists available references with their description, number of female ports, extension tubing length (cm) and packaging quantities.

Table
Reference | Description | Female ports | Extension tubing length (cm) | Inner box qty. | Outer box qty.
RPB2305 | 2 stopcocks manifolds with male/male extension line | 4 | 50 | 20 | 320
RPB2310 | 2 stopcocks manifolds with male/male extension line | 4 | 100 | 20 | 320
RPB2315 | 2 stopcocks manifolds with male/male extension line | 4 | 150 | 20 | 320
RPB2320 | 2 stopcocks manifolds with male/male extension line | 4 | 200 | 20 | 320
RPB3305 | 3 stopcocks manifolds with male/male extension line | 5 | 50 | 20 | 320
RPB3310 | 3 stopcocks manifolds with male/male extension line | 5 | 100 | 20 | 320
RPB3315 | 3 stopcocks manifolds with male/male extension line | 5 | 150 | 20 | 320
RPB3320 | 3 stopcocks manifolds with male/male extension line | 5 | 200 | 20 | 320
RPB4305 | 4 stopcocks manifolds with male/male extension line | 6 | 50 | 15 | 240
RPB4310 | 4 stopcocks manifolds with male/male extension line | 6 | 100 | 15 | 240
RPB4315 | 4 stopcocks manifolds with male/male extension line | 6 | 150 | 15 | 240
RPB4320 | 4 stopcocks manifolds with male/male extension line | 6 | 200 | 15 | 240
RPB5305 | 5 stopcocks manifolds with male/male extension line | 7 | 50 | 15 | 240
RPB5310 | 5 stopcocks manifolds with male/male extension line | 7 | 100 | 15 | 240
RPB5315 | 5 stopcocks manifolds with male/male extension line | 7 | 150 | 15 | 240
RPB5320 | 5 stopcocks manifolds with male/male extension line | 7 | 200 | 10 | 160
RPB6305 | 6 stopcocks manifolds with male/male extension line | 8 | 50 | 10 | 160
RPB6310 | 6 stopcocks manifolds with male/male extension line | 8 | 100 | 10 | 160
RPB6315 | 6 stopcocks manifolds with male/male extension line | 8 | 150 | 10 | 160
RPB6320 | 6 stopcocks manifolds with male/male extension line | 8 | 200 | 10 | 160

Regulatory information
Medical Device: Class IIa, CE 0459. Read the instructions for use and the rules for safe use indicated in the leaflet.

Technical characteristics / specifications

• Product family: Manifolds with coextruded PE/PVC extension lines (infusion accessories)
• Material: coextruded PE/PVC (extension tubing coextruded PE/PVC)
• Available configurations: 2, 3, 4, 5 and 6 stopcock manifolds (references RPB23xx, RPB33xx, RPB43xx, RPB53xx, RPB63xx)
• Female ports: 4 (2‑stopcock), 5 (3‑stopcock), 6 (4‑stopcock), 7 (5‑stopcock), 8 (6‑stopcock)
• Extension tubing lengths available (cm): 50, 100, 150, 200
• Packaging: inner box and outer box quantities provided per reference (see table)
• Classification: Medical Device Class IIa, CE marked (0459)
