Semi-automatic external defibrillator G series

fully automaticfor public spacefor emergency vehicles

Overview
Designed for rapid lifesaving intervention, the G-Series external defibrillators provide an intuitive, responder-focused workflow with advanced cardiac rhythm analysis and clear automated step-by-step guidance. The device reduces required actions for lay and professional rescuers to enable fast, confident defibrillation in emergency settings.

Rescue timeline

• Full operational readiness in under 2 seconds after lid opening.
• Rhythm analysis and 200 J charging completed within approximately 5 seconds.
• Ready-to-shock sequence completed in ≤ 7 seconds total.

Key features

• Minimalist operation and responder-focused workflow to reduce response steps in emergencies.
• Pre-connected adult and pediatric electrode pads for immediate application.
• Automatic volume adjustment to ensure audible guidance in noisy environments.
• Supports patient impedances from 20 Ω to 300 Ω (maximum tolerance 300 Ω).
• Meets EN1789 ambulance transport standard.
• Ingress protection IP55 and 1.5 m drop resilience for reliable field use.
• Available in semi-automatic and fully automatic models (G3 / G3A / G5 / G5A).

Electrodes and accessibility

• Adult and pediatric pads supplied pre-connected; clear labeling and ergonomics speed placement and reduce handling time.

Product safety and performance information
Product safety and performance documentation (PDF) is available for models G3, G3A, G5 and G5A.

Technical specifications

• Model designation: G3, G3A, G5, G5A
• Energy/Charging: 200 J charge (analysis and charging performed simultaneously)
• Operational readiness: < 2 seconds after lid opening
• Analysis + 200 J charge: ~5 seconds
• Ready-to-shock: ≤ 7 seconds
• Electrodes: pre-connected adult and pediatric pads
• Impedance range: 20 Ω – 300 Ω (max tolerance 300 Ω)
• Acoustic: automatic volume adjustment for noisy environments
• Certifications/Standards: EN1789 (ambulance transport)
• Ingress protection: IP55
• Drop resilience: 1.5 m
• Intended use: semi-automatic and fully automatic external defibrillator for emergency/rescue use
