Panel PC computer cart KRT-P-1324

with drawerheight-adjustablesecure

Product description
Mobile medical computer workstation cart designed for clinical mobility and point-of-care use. Model TR800-200-3 features a mechanical height-adjust lift with a 400 mm adjustment range, integrated monitor mount and modular accessory options to adapt to ward, clinic and emergency workflows.

Typical application scenarios

• Ward rounds: mobile equipment transport and bedside use for rapid documentation and review.
• Nursing documentation: bedside data entry and charting during patient care.
• Outpatient shared terminals: flexible shared workstation for clinics and reception areas.
• Bedside monitoring and data capture: portable platform for point-of-care devices and screening.

Equipment adaptation and workflow value
The TR800-200-3 serves as a centralized mobile workstation to integrate main computing units, displays, input devices, power modules and cable management. Its modular layout allows selection of components per department and device brand, reducing fixed-station constraints and enabling equipment to follow clinical workflows.

Adaptation direction

• Laptop
• All-in-one PC or small host
• Monitor and keyboard/mouse
• Scanners, power supplies and storage accessories

Design highlights

• Ergonomic operation: suitable for standing, seated and bedside tasks.
• Information terminal integration: consolidates computer, display and input devices on a mobile platform.
• Security and anti-theft options: suitable for public clinical areas.
• Flexible expansion: supports varied power modules, hosts, storage and barcode/QR scanning accessories.

Recommended accessories

• Double drawer with lock - 470 × 350 × 260 mm
  • Size: 470 × 350 × 260 mm
  • Weight: 10 kg
  • Maximum weight load in drawer: 7 kg
• Locked anti-theft desktop - push-pull keyboard tray
  • Table outside size: 511 × 538 mm
  • Usable size: 473 × 323 mm
  • Cup holder diameter: 78 mm
  • Depth of cup holder: 75 mm
  • Keyboard holder outside size: 449 × 240 mm
  • Keyboard holder usable size: 442 × 158 mm
  • Mouse holder outside size: 162 × 183 mm
  • Mouse holder usable size: 153 × 165 mm
  • Material: steel plate, ABS/PC
• Standard desktop - hidden keyboard
  • Table outside size: 511 × 538 mm
  • Usable size: 473 × 323 mm
  • Keyboard holder usable size: 413 × 158 mm
  • Mouse holder outside size: 138 × 170 mm
  • Material: steel plate, ABS/PC

Technical specifications

• Model: TR800-200-3
• Brand: CORITON
• Page code: KRT-P-1324
• Screen bracket max load: 20 kg
• Table max load: 10 kg
• Keyboard holder max load: 2.5 kg
• Screen tilt angle: 0–15°
• Screen horizontal rotation: ±90°
• Height adjust method: mechanical lifting
• Height adjust range: 400 mm
• Trolley top to ground height: 1200–1600 mm
• Caster: 4" (all with brake)
• Material: aluminum, steel plate, ABS/PC
• Package (assembled): 750 × 660 × 1700 mm
