Closing machine for the pharmaceutical industry Twin Tie®

compactpneumatic

PNEUMATIC TIGHTENING TOOL. The Twin Tie® clamps must be manually pulled over the liner before being compressed with the tool to ensure a complete and secure seal. CSV Containment offers two excellent solutions for closing the Twin Tie®: manual or pneumatic tightening tools. The choice between the two depends largely on the type and frequency of crimping operations. In fact, the pneumatic tool is recommended when there is a large number of sealing operations and especially with continuous liners. However, the pneumatic tool is not recommended for big bags and very large necks. In this case, manual tightening tool, which does not require compressed air, is the best solution. Main features of the pneumatic tool: • Maximum torque: 1,400 N at 6 bar. • Compressed air. • Clamp opening min - max: 120 mm - 210 mm. • Ergonomic handle. • Push button activation. • Weight: 1.9 kg.
