Pharmaceutical product packaging box ORCA S 23L

transportpapertemperature-controlled

Product overview
ORCA Single-Use 23L is a single-use, passive temperature-controlled parcel shipper designed for transporting high-value, temperature-sensitive payloads. It combines vacuum insulated panels (VIP) and phase change materials (PCM) to deliver extended-duration thermal stability without active power.

Key features

• Single-use passive thermal packaging using VIP/PCM technology
• Designed for high-value, temperature-sensitive payloads
• Extended duration thermal protection (example: 96 hours, depending on configuration)
• Available pre-conditioning to required set point before dispatch
• Optional data logger integration for temperature monitoring
• Shipping configurations: single unit or full pallet of 24 units

Available configurations / options

• Temperature ranges: 15°C–25°C and 2°C–8°C
• Pre-conditioned: yes / no
• Shipping configurations: single-unit; full-pallet (24 single units)
• Logger integration: optional (yes / no)

Pricing & availability notes (as shown on page)

• Example displayed price: £266.40 (GBP); other variations shown on page: £335.40, £352.80 depending on options
• Product availability: In stock (per product metadata)

SKU / identifiers

• Primary SKU: ORCS23L
• Other variation SKUs: OSU333-PALL24, OSU333, OSU333+SLOG001, PREPOSU333, PREPOSU333+SLOG001, OSU332+SLOG001, OSU331+SLOG001

Notes

• Product images show ORCA Single-Use branding (front and angle views)
• Some variations include an environmental trees-planted message when selected

Technical specifications

• External dimensions: 435 mm x 430 mm x 420 mm
• Payload dimensions: 290 mm x 290 mm x 280 mm
• Payload volume: 23.5 L
• Mass: 14.7 kg
• Duration (example configuration): 96 hours
• Temperature ranges available: 15°C–25°C; 2°C–8°C
• Product type: single-use passive temperature-controlled parcel shipper
• Available options: pre-conditioned (yes/no), logger integration (yes/no), shipping configuration (single-unit / full-pallet 24 units)
• Primary SKU: ORCS23L
