Long walker boot MaxTrax™ Air

articulatedinflatable

Product overview
Provides a protected range-of-motion solution for foot and ankle following trauma or surgical procedures. ROM adjustable between 45° plantar-flexion and 30° dorsiflexion in 7.5° increments. Uprights lock in fixed positions at 0°, 7.5°, 15°, 22.5° and 30° for plantar- and dorsiflexion. Integrated pneumatic liner and pump accommodate oedema and facilitate progressive rehabilitation.

Indications

• Post-operative or functional management of Achilles tendon rupture
• Foot and ankle injuries or stable fractures requiring protected ROM
• Post-operative immobilisation following foot and ankle procedures

Features

• Adjustable pneumatic air chambers to manage changes in oedema
• ROM settings from 45° plantar-flexion to 30° dorsiflexion in 7.5° increments
• Lockable uprights at 0°, 7.5°, 15°, 22.5° and 30°
• Low-profile rocker bottom to promote natural gait
• Cushioned inner and outer sole engineered to absorb heel-strike shock
• Integrated pump for simple liner inflation
• Swivelling D-ring allowing crisscross or parallel strapping for secure fixation
• Malleable uprights can be shortened for shorter tibia/fibula on standard-height walker

Ordering information

• Part Number — UK Shoe Size (Men) — UK Shoe Size (Women) — EU Shoe Size — Size
• 11-1381-1 — - — Up to 1.5 — < 34 — XS
• 11-1381-2 — Up to 4.5 — 2 - 3.5 — 34 - 37.5 — S
• 11-1381-3 — 5 - 9.5 — 4 - 8.5 — 38 - 43.5 — M
• 11-1381-4 — 10 - 13 — 9 - 12 — 44 - 46.5 — L
• 11-1381-5 — 13.5 - 17.5 — - — > 47 — XL

Technical specifications

• Adjustable pneumatic air chambers with integrated pump
• ROM range: 45° plantar-flexion to 30° dorsiflexion, adjustable in 7.5° increments
• Lockable uprights at specified angles
• Low-profile rocker sole for natural gait
• Cushioned inner and outer sole for shock absorption
• Swivelling D-ring for multiple strapping configurations
• Malleable, removable uprights for tibia/fibula length adjustment
• Available sizes: XS, S, M, L, XL
