Laboratory water distiller M8

compact

Description
The M8 water still delivers a continuous distillation capacity of 8 liters per hour for laboratories and technical facilities that require increased volumes of distilled water. It uses stainless steel tube heating elements, includes an external water filter to stabilise feed quality, and incorporates safety systems such as water level monitoring and automatic leakage-current fuses. The unit has a stainless steel casing and a compact footprint (72 x 66 x 34 cm) suitable for busy lab environments.

Comparison Table for M4, M8, and M12 Water Stills
Feature — M4 — M8 — M12
Distillation Capacity — 4 liters/hour — 8 liters/hour — 12 liters/hour
Cooling Water Usage — 40 liters/hour — 80 liters/hour — 120 liters/hour
Output Water Temp. — 50°C — 50°C — 50°C
Heater Type — Stainless steel tube — Stainless steel tube — Stainless steel tube
Safety Features — Water level control, magnetic switch, leakage current fuse — Same as M4 — Same as M4
Casing Material — Stainless steel — Stainless steel — Stainless steel
Internal Tank Capacity — 8 liters — 16 liters — 24 liters
Power Rating — 3000 W — 3×2 kW — 3×2.4 kW
Dimensions (w x h x d) — 65 x 52 x 25 cm — 72 x 66 x 34 cm — 72 x 66 x 34 cm
Net Weight — 18 kg — 32 kg — 32 kg

Frequently Asked Questions

• What is the difference between M4, M8, and M12 Water Stills?
  The primary differences are distillation capacity (M4: 4 L/h, M8: 8 L/h, M12: 12 L/h), with corresponding increases in cooling water consumption, internal tank capacity, and power rating.
• Are these water stills energy-efficient?
  All models use stainless steel tube heating elements that provide efficient heat transfer; combined with their safety and control systems, this helps limit energy waste during operation.
• What safety features are included?
  Each model is equipped with water level control, a magnetic switch, and a leakage-current fuse (automatic fuses) to ensure safe operation and protect the heater circuits.
• Is the water output temperature adjustable?
  The output water temperature for these models is specified at 50°C.
• Do these water stills require regular maintenance?
  Regular cleaning of the stainless steel chamber and periodic replacement or maintenance of the external water filter are recommended to maintain performance and longevity.

Technical specifications

• Model: M8
• Distillation capacity: 8 liters/hour
• Internal tank capacity: 16 liters
• Cooling water usage: 80 liters/hour
• Output water temperature: 50°C
• Heater type: Stainless steel tube resistance
• Safety features: Water level control, magnetic switch, leakage-current fuse (automatic fuses)
• Casing material: Stainless steel
• Power rating: 3×2 kW
• Dimensions (w x h x d): 72 x 66 x 34 cm
• Net weight: 32 kg
