Sterilization service workstation FW-P139D

nursing carewith shelveswith drawers

Product name
FW-P139D Supply Room Workstation

Core advantages
The FW-P139D supply room workstation is engineered for CSSD and anesthesia/resuscitation workflows with an integrated layout. A stainless-steel arch medication rack holds 20 high-transparency ABS medication bins for efficient, clearly categorized access. Dual side-by-side drawers use a 3x3 modular divider system for graded storage. The H‑section steel frame provides high rigidity; medical-grade worktop resists chemicals and is easy to disinfect. Heavy-duty three-stage silent rails with anti-derail and damping ensure reliable operation suitable for frequent clinical use.

Application scenarios
Core applications include central sterile supply departments, operating rooms, anesthesia recovery and clinical preparation areas. Typical uses: anesthetic drug management, consumable picking and packing, instrument sorting and storage, intraoperative rapid replenishment and supply turnover while meeting strict decontamination standards.

1. Frame structure system
Main structure uses high-strength cold-rolled steel columns with H-type support frame delivering superior rigidity and long-term stability. Surface treated with industrial electrostatic powder coating for abrasion and corrosion resistance. Reinforced crossbeams minimize deformation under long-term service and multi-user operations.

2. Worktop and base structure system
Worktop is 12 mm thick, 1500ρ high-density medical-grade HPL compact board combining wear, chemical resistance, waterproof and easy-clean properties. Base and columns use concealed reinforced connections to ensure even stress distribution and long-term dimensional stability.

3. Medication bin flip-rack module
Arch rack is formed from food-grade stainless steel, robust and easy to sanitize to medical cleanliness standards. Supplied with removable double-row high-transparency ABS bins (20 total, 10 per row) featuring flip-open action for high-frequency access. Each bin includes an ID card slot for fast identification. Integrated recessed dispenser holder (right side) reduces cross-contamination risk. Lower section includes three removable stainless-steel storage boxes for consumables and tools.

4. Modular drawer system
Dual side-by-side drawers: front panel height 110 mm, internal height 90 mm to accommodate varied items. Standard modular divider system based on a 3x3 grid supports horizontal and vertical repositioning and combinations; divider height 60 mm enabling 1–12 compartment configurations. Drawers employ a double-layer aluminum-alloy one-piece frame with chamfered edges; bottom panel is 4 mm high-density aluminum-plastic composite with medical-grade PEVA anti-slip & noise-dampening mat for easy cleaning. Each drawer level includes five 42×65 mm ID windows and integrated ABS label slots on the front for clear organization.

5. Slide rails system
Equipped with precision three-stage heavy-duty silent rails (45 mm width) with material thicknesses of 1.2/1.2/1.5 mm. Built-in damping mechanism provides soft closing; anti-misopen lock prevents accidental drawer ejection. Single-drawer static rated load ≥ 15 kg, suitable for high-frequency use.

6. Transport and mobility system
Front disc-type fixed support combined with rear dual caster assembly separates static and mobile states. Lift front end for low-effort translation; movement is smooth without sticking and locks stably for stationary use, enabling rapid switching between scenes.

7. Safety protection system
All worktop and structure edges are fully radius‑rounded to reduce knock and scratch hazards. Overall rated load capacity ≥ 150 kg with strong anti‑tilt and anti‑slip properties to maintain stability during multi-operator use and secure clinical operations.

8. Cleaning and maintenance system
Surfaces are smooth and non-porous with high chemical resistance compatible with medical disinfectants. Designed for frequent wiping and disinfection: water-repellent, mold-resistant and easy to sanitize to meet hospital infection control protocols.

9. Customization and expansion system
Quick-release modular design facilitates transport, maintenance and flexible deployment. Supports integration of information terminals, cable management and auxiliary support modules. Expansion options include electric lift, multifunctional storage modules and other configurable accessories to adapt to evolving clinical requirements.

Features/Technical specifications

• Model: FW-P139D
• Commercial name: Supply Room Workstation
• Dimensions: 1390×600×800 mm
• Frame material: High-strength cold-rolled steel columns, H-type support frame, electrostatic powder coating
• Worktop: 12 mm thick 1500ρ high-density medical-grade HPL Compact Board
• Medication bins: Removable double-row high-transparency ABS bins, 20 total (10 per row), each with ID card slot
• Lower storage: Three removable stainless-steel storage boxes
• Drawer structure: Dual side-by-side drawers, front panel height 110 mm, internal height 90 mm; divider height 60 mm, supports 1–12 compartment configurations
• Drawer materials and bottom panel: Double-layer aluminum-alloy one-piece frame; 4 mm high-density aluminum-plastic composite bottom panel with medical-grade PEVA anti-slip noise-dampening mat
• Drawer labeling: Each drawer level with five 42×65 mm ID windows; integrated ABS label slot on front
• Slide rails: Three-stage heavy-duty silent rails, 45 mm width, material thickness 1.2/1.2/1.5 mm; built-in damping and anti-misopen lock
• Single-drawer static rated load: ≥ 15 kg
• Overall rated load capacity: ≥ 150 kg
• Mobility system: Front disc-type fixed support + rear dual caster combination for easy translation and stable fixation
• Meets hospital cleaning and disinfection requirements; surface chemical resistant and easy to clean
• Supports customization and expansion: Quick-release design; options for information terminals, electric lift and multifunctional storage modules
