Floor-mounted cryotherapy bathtub Cryobain

Overview
Our Cryobain ice baths are offered in three dedicated models to support athlete recovery after training or competition while maintaining user comfort and safety.

Models

• Cryoplus: Designed for tall users; omission of the third step saves space and improves standing/sitting comfort during immersion.
• Cryobain: Core model of the range. Adjustable immersion depth for sit/stand/full-body configurations to adapt posture to the treated area.
• Cryoduo: Two-person standing tub. Teak and stainless-steel steps replace polyester steps to double available internal space for two standing users.

Benefits

• Supports faster recovery and reduces post-exercise fatigue.
• Stimulates circulation and helps limit muscle soreness.
• Combines cold thermal shock and hydrostatic pressure for effective recovery outcomes.

Technical description
General

• Made in France
• Fiberglass and polyester resin basin (low thermal loss)
• Stainless-steel handrails and steps
• Removable protective cover
• Integrated cooling unit and filtration system
• Digital temperature display and control
• Electrical consumption: 5 A/day (maximum load)
• Refrigerant: R410
• Supply frequency: 50 Hz
• Cooling performance: -3 °C per hour

Dimensions

• Overall (L x W x H): 190 x 80 x 120 cm
• Water height: 90 cm
• Basin capacity: 500 L
• Empty weight: 180 kg
• Filled weight: 680 kg

Installation

• Power supply: 230 V / single phase / 50 Hz
• Standard water inlet for filling
• Drainage: 1-inch quarter-turn valve at the low point
• Ventilated room recommended for condensation control

Customization

• Choice of the 3 standard configurations
• Possibility to build custom pools to match specific projects (sizes up to multi-person units)
• Custom color and exterior shell finishes to match club or facility branding
• Logo application on outer shell available
• Optional accessories: cartridge filtration, teak step option (Cryoduo)

Compliance

• CE marking
• 93/68/CEE relative to CE marking
• 97/23/CE – European Pressure Equipment Directive (PED)
• EN 378 – parts 1–4 (refrigeration installations)
• EN 13133 – refrigeration engineer qualification
• N.F. EN
• N.F C 15-100 sections 701 and 751

Recommended operating temperature
Baths typically operate between 7 and 12 °C. To remain liquid, water temperature must be kept above 0 °C. A common guideline: immersion time in minutes roughly equals water temperature in °C (e.g., 7 minutes at 7 °C).

Technical specifications

• Origin: France
• Basin material: Fiberglass and polyester resin
• Handrails / steps: Stainless steel (teak option for Cryoduo)
• Protective cover: Removable
• Cooling & filtration: Integrated unit and filtration system
• Temperature control: Digital display
• Electrical consumption: 5 A/day (max)
• Refrigerant: R410
• Cooling performance: -3 °C / hour
• Supply frequency: 50 Hz
• Overall dimensions (L x W x H): 190 x 80 x 120 cm
• Water height: 90 cm
• Capacity: 500 L
• Empty weight: 180 kg / Filled weight: 680 kg
• Power supply requirement: 230 V / single phase / 50 Hz
• Drain: 1-inch quarter-turn valve at low point
• Room requirement: Ventilated environment for condensation control
• Customization: color, logo branding, custom sizes (multi-person options)
• Standards: CE, PED, EN 378, EN 13133, N.F. EN, N.F C 15-100 (701 & 751)
