Physical therapy laser NOMAD

diodecontinuousclass 4

Overview
The NOMAD is a portable high-power Class IV laser therapy system designed for clinical, therapeutic, and veterinary use. FDA 510(k) cleared. Core specifications include 42 W continuous output (57 W in INTENSE SUPERPULSE mode), five selectable wavelengths, a removable 4-hour lithium-ion battery for cordless operation, and a 5-year manufacturer warranty.

Key features

• Maximum power: 42 W continuous wave (CW); up to 57 W in INTENSE SUPERPULSE (ISP) mode
• Five wavelengths: 1064 nm, 980 nm, 915 nm, 810 nm, 635 nm — multi-wavelength platform for varied tissue depth and responses
• INTENSE SUPERPULSE (ISP) mode: variable duty-cycle pulsing to stimulate deeper tissues while reducing surface heating
• Removable 4-hour lithium-ion battery: Full power ≈ 0.5 hour; reduced-power operation up to 4 hours; standby up to 7 days; hot-swap replacement without tools
• Folding 10-inch touchscreen with intelligent treatment software: parameter selection by diagnosis, BMI and skin type; pre-loaded protocols and custom protocol creation/saving
• Five-lens applicator set included: large-area open zoom, curved deep-tissue contact lenses, precision spot lens, TMJ/small-joint lens
• Portable cordless operation for clinic, sideline or field use
• Five-year full manufacturer warranty
• Financing options available (example: NCMIC)

Included lenses

• 30 mm open zoom lens — large-area non-contact treatment
• 30 mm curved contact lens — deep-tissue contact
• 10 mm curved contact lens — precision spot
• 5 mm TMJ lens — jaw and small joints

Battery & operation

• Full power runtime: approximately 0.5 hour
• Reduced power runtime: up to 4 hours
• Standby: up to 7 days
• Hot-swap removable battery: replaceable without tools for continuous operation

Other product highlights

• Pre-loaded clinical protocols and the ability to save custom protocols per patient
• Intelligent dosing selection by diagnosis, BMI and skin type to simplify parameter selection
• Sold direct from manufacturer; listed price and financing examples available

Comparison (excerpt)
Model / Brand | GIGAA NOMAD | A | Summus Laser | LightForce | Diowave
Price | $24,995 | $35K–$45K | $38K–$48K | $35K–$50K | $30K–$42K
Max Power | 42W CW / 57W ISP | Up to 30W | Up to 25W | Up to 60W | Up to 30W
Wavelengths | 5 | 2–3 | 2–3 | 2 | 2–3
Battery (4 hr) | ✓ YES | ✗ No | ✗ No | ✗ No | ✗ No
Cordless Use | ✓ YES | Limited | ✗ No | ✗ No | Limited
Sold Direct | ✓ YES | ✗ Dealer | ✗ Dealer | ✗ Dealer | ✗ Dealer
Warranty | 5 Years | 1–3 Yrs | 1–2 Yrs | 1–2 Yrs | 1–2 Yrs
Financing | NCMIC ~ $520/mo | Varies | Varies | Varies | Varies

Applications

• Chiropractic
• Physical therapy
• Sports medicine
• Athletic training
• Veterinary rehabilitation
• Equine medicine

Characteristics / Technical specifications

• Commercial name / model: NOMAD
• Manufacturer / brand: Gigaa Med USA
• Class: Class IV laser, FDA 510(k) cleared
• Max continuous power: 42 W (continuous wave)
• Max ISP power: 57 W (INTENSE SUPERPULSE mode)
• Wavelengths: 1064 nm, 980 nm, 915 nm, 810 nm, 635 nm
• Battery: Removable lithium-ion; full power ~0.5 hour, reduced power up to 4 hours, standby up to 7 days; hot-swap replaceable without tools
• Applicators included: 30 mm open zoom lens, 30 mm curved contact lens, 10 mm curved contact lens, 5 mm TMJ lens
• User interface: Folding 10-inch touchscreen with intelligent treatment software; pre-loaded and custom protocols
• Regulatory: FDA 510(k) cleared
• Warranty: 5-year full warranty
• Price (listed): $24,995 direct from manufacturer
• Financing: NCMIC example (~$520/month referenced)
• Intended use: Clinical (chiropractic, physical therapy, sports medicine, athletic training), veterinary rehabilitation, equine medicine
