Conical dental implant HT™

titaniumconicalinternal hexagon

Product description
Glidewell HT™ Implants provide clinicians precise control at placement, engage a maximal amount of bone and deliver high primary stability across a wide range of clinical situations. The unique, sharply angled thread pattern with self-tapping grooves supports efficient insertion. All Glidewell HT™ Implants incorporate a conical internal-hex prosthetic connection and color-coded restorative components for streamlined prosthetic workflows.

Key features

• Conical internal-hex prosthetic connection for a secure prosthetic seal
• Sharply angled, self-tapping thread pattern for swift insertion and strong primary stability
• Color-coded components by implant diameter and/or restorative platform
• Shared restorative platform for 3.5 mm and 4.3 mm diameters to reduce system complexity

Availability and dimensions

• Available diameters: 3.0 mm, 3.5 mm, 4.3 mm, 5.0 mm, 7.0 mm
• Available lengths: 8 mm, 10 mm, 11.5 mm, 13 mm, 16 mm
• 3.0 mm implants intended for anterior applications only; 7.0 mm implants intended for posterior applications only
• 3.5 mm and 4.3 mm implants share the same prosthetic platform

Clinical indications

• Indicated for restorative cases requiring tapered implant geometry, including single-tooth and multi-unit restorations when clinically appropriate
• Select implant diameter and length according to site anatomy, bone quality and restorative plan; narrow diameters for anterior sites, wider diameters for posterior load-bearing sites

Product resources

• Glidewell HT Implant System Brochure
• Glidewell HT Implant System Surgical Manual
• Glidewell HT Implant Guided Surgery Manual
• Glidewell HT Implant Product Catalog
• Glidewell HT Implant Restorative Manual
• Glidewell HT Implant Guided Surgery System Instructions for Use
• Glidewell HT Implant Clinical and Radiographic Evaluation Study
• Glidewell HT Implant Cervical Collars White Paper

Additional product information

• Manufacturer: Prismatik Dentalcraft, Inc.
• Product Code (SKU): 70-1189-IMP0001
• Product type: Tapered implant

Technical specifications

• Series: Glidewell HT™
• Connection: Conical internal hex prosthetic connection
• Thread: Sharply angled self-tapping grooves
• Color-coding: Matching components color-coded by implant diameter and/or restorative platform
• Available diameters: 3.0 mm, 3.5 mm, 4.3 mm, 5.0 mm, 7.0 mm
• Available lengths: 8 mm, 10 mm, 11.5 mm, 13 mm, 16 mm
• Intended applications: 3.0 mm implants for anterior only; 7.0 mm implants for posterior only
• Prosthetic platform: 3.5 mm and 4.3 mm implants share the same restorative platform
• SKU / Variant: Default variant id shown with visible price mapping to $99.00
