Anesthesia syringe pump HY-902A

1-waypediatriccontinuous

Overview
The HY-902A is a compact clinical syringe pump designed for accurate volumetric infusion with standard 5, 10, 20, 30 and 50/60 ml syringes. Dual-CPU architecture and multiple safety functions support continuous use in wards, ICUs and ambulatory care.

Key features

• Independent control interfaces to prevent operator interference
• Dual CPU system for enhanced reliability
• Infusion modes: Flow rate, Time/Volume, Drug/Weight, BOLUS
• Compatible with standard syringes 5–60 ml
• Dynamic pressure display and 3-level occlusion sensitivity
• Anti-bolus function: automatic release of impact dose after occlusion
• Vertical and horizontal rotating fixation clamp
• Stores up to 2000 history records
• Upgradable drug library and wireless monitoring options

Technical specifications

• Syringe compatibility: 5 ml, 10 ml, 20 ml, 30 ml, 50/60 ml
• Flow rate ranges: 5 ml: 0.1–150 ml/h; 10 ml: 0.1–300 ml/h; 20 ml: 0.1–400 ml/h; 30 ml: 0.1–600 ml/h; 50 ml: 0.1–1200 ml/h
• Flow rate step: 0.1 ml/h
• Flow rate accuracy: ±2% (including mechanical ±1%)
• Volume limit: 0.1–9999.9 ml
• Purge/Bolus max rates depend on syringe size (up to 1200 ml/h for 50 ml)
• BOLUS ranges: same as flow rate ranges
• KVO (Keep Vein Open): 1 ml/h
• Alarms: multi-level occlusion, empty/near empty, battery low, motor/system fault, incorrect parameter setting, AC power loss
• Memory: 2000 records
• Display: 2.8" TFT
• Power: ≤25 W, AC 85–265 V, 50/60 Hz; Backup battery DC 12 V, 2000 mAh (~4 h at 25 ml/h)
• Operating conditions: +5 °C to +40 °C, RH ≤80%, 70–106 kPa
• Dimensions: 356 × 192 × 134 mm
• Weight: 2.9 kg

Clinical applications

• Continuous IV infusion in hospitals and clinics
• ICU and neonatal units (precise low-flow delivery)
• Anesthesia and perioperative drug administration
• Ambulatory infusion and infusion therapy at bedside

Ordering information

• Model: HY-902A
• Optional: drug library upgrade, wireless monitoring module
• Accessories: syringe clamps and mounting brackets available
