Membrane filter BIOFIL
cartridgebacterialwater

Membrane filter - BIOFIL - H2O Equipement - cartridge / bacterial / water
Membrane filter - BIOFIL - H2O Equipement - cartridge / bacterial / water
Membrane filter - BIOFIL - H2O Equipement - cartridge / bacterial / water - image - 2
Membrane filter - BIOFIL - H2O Equipement - cartridge / bacterial / water - image - 3
Membrane filter - BIOFIL - H2O Equipement - cartridge / bacterial / water - image - 4
Membrane filter - BIOFIL - H2O Equipement - cartridge / bacterial / water - image - 5
Add to favorites
Compare this product
Go to the H2O Equipement website for more information

Characteristics

Filter type
membrane, cartridge, bacterial
Fluid
water
Applications
for the food industry, medical, for hospitals, for healthcare facilities, for tap
Material
polyethylene, ABS, polysulfone
Connection type
integrated
Other characteristics
with check valve, tubular
Filtration capacity

Min.: 0.1 µm

Max.: 0.2 µm

Description

Product overview
  • Sterilizing-grade filtration devices designed to protect showers, taps and kitchen sprays against Legionella and other germs.
  • Intended applications: nursing homes, retirement homes, care homes, healthcare facilities, hospitals, clinics, hotels, campsites, sports and educational facilities, commercial and hospital kitchens.

31 days (1 month) shower filter
  • Shower filter against Legionella.
  • Device material: ABS.
  • Membrane type: tubular microfiltration.
  • Membrane material: Polysulfone.
  • Cut-off rating: sterilizing-grade filter, 0.2 μm tubular membrane.
  • Maximum upstream operating pressure: 5 bar.
  • Maximum upstream operating temperature: 60°C.
  • Maximum usage duration: 31 days after installation.
  • Flow regulator: constant flow technology.
  • Integrated check valve prevents back contamination during filter replacement.
  • Thermal shock resistance: 70°C for 30 minutes.
  • Chemical shock resistance: 1000 ppm of active chlorine for a cumulative 1 hour.
  • Traceability: GS-1 DataMatrix.
  • Flow rate: 3.9 L/min at 1 bar; 8.7 L/min at 3 bar; 9.4 L/min at 5 bar.

2 months shower filter (BIOFIL)
  • BIOFIL filtered shower head against Legionella and all germs.
  • Device material: ABS.
  • Membrane type: tubular microfiltration.
  • Membrane material: Polyethylene.
  • Cut-off rating: 0.1 μm nominal and 0.2 μm absolute (sterilizing grade).
  • Qualified water volume by usage duration: 6,000 liters.
  • Filtration flow rate (filter only, without flow restriction in the faucet): 6 L/min at 1 bar; 11.2 L/min at 3 bar; 13 L/min at 5 bar.
  • Maximum upstream operating pressure: 5 bar.
  • Maximum usage duration: 2 months after installation.
  • Thermal shock resistance: 70°C for 30 minutes.
  • Chemical shock resistance: 100 ppm of active chlorine for a cumulative 2 hours.
  • CE Class I medical device.

3 months shower filter (BIOFIL)
  • BIOFIL filtered shower head against Legionella and all germs.
  • Device material: ABS.
  • Membrane type: tubular microfiltration.
  • Membrane material: Polyethylene.
  • Cut-off rating: 0.1 μm nominal and 0.2 μm absolute (sterilizing grade).
  • Qualified water volume by usage duration: 9,000 liters.
  • Filtration flow rate (filter only, without flow restriction in the faucet): 6 L/min at 1 bar; 11.2 L/min at 3 bar; 13 L/min at 5 bar.
  • Maximum usage duration: 3 months after installation.
  • Thermal shock resistance: 70°C for 30 minutes.
  • Chemical shock resistance: 100 ppm of active chlorine for a cumulative 2 hours.
  • CE Class I medical device.

4 months shower filter
  • Faucet and wall-mounted shower filter against Legionella and all germs, shower spray.
  • Device material: ABS.
  • Membrane type: tubular microfiltration.
  • Membrane material: Polyethylene.
  • Cut-off rating: 0.1 μm nominal and 0.2 μm absolute (sterilizing grade).
  • Water volume: 12,000 liters.
  • Filtration flow rate (filter only, without flow restriction in the faucet): 4.6 L/min at 1 bar; 7.6 L/min at 3 bar; 9.4 L/min at 5 bar.
  • Controlled back-contamination management: protective skirt and angled connection for optimal positioning.
  • Maximum pressure: 5 bar.
  • Maximum usage duration: 4 months.
  • Thermal shock resistance: 70°C for 30 minutes.
  • Chemical shock resistance: 100 ppm of active chlorine for a cumulative 4 hours.
  • CE Class I medical device.

Legionella protection filters for hotels / public buildings
  • Sterilizing-grade filter with 0.2 μm membrane.
  • High filtration capacity, lifespan up to 92 days (depending on version).
  • Minimalist and modern design; constant flow technology to maintain optimal flow throughout lifecycle.
  • Replaceable filter cartridge system for extended lifespan and reduced overall cost.
  • Integrated check valve to prevent upstream contamination by backflow (where specified).
  • Typical flow rate example: 8 L/min (example value given for some hotel variant).
  • Maximum operating temperature: 60°C (where specified).

Legionella kitchen / tap / spray filters
  • Sterilizing-grade filter with 0.2 μm membrane for kitchen faucet sprays.
  • High filtration capacity, typical lifespan examples up to 92 days depending on model and water quality.
  • Constant flow technology and intelligent nozzle design to ensure high-velocity water flow.
  • Dual operating mode (shower head can be used with or without filter) on some models.
  • Integrated check valve to prevent upstream contamination by backflow.
  • Suitable uses: industrial dishwashers, rinsing fruits and vegetables, commercial kitchens, hospital kitchens.

Caractéristiques / spécifications techniques
  • Device material: ABS (common across variants).
  • Membrane type: tubular microfiltration.
  • Membrane materials: Polysulfone (some 1-month variant) or Polyethylene (most multi-month variants / BIOFIL).
  • Cut-off rating: 0.2 μm absolute (sterilizing grade); some variants specify 0.1 μm nominal + 0.2 μm absolute.
  • Maximum upstream operating pressure: typically 5 bar.
  • Maximum operating temperature: typically 60°C.
  • Thermal shock resistance: 70°C for 30 minutes (specified for several variants).
  • Chemical shock resistance: varies by model (examples: 1000 ppm active chlorine cumulative 1 hour; 100 ppm cumulative 2 hours; 100 ppm cumulative 4 hours depending on version).
  • Maximum usage duration / lifespan: examples include 31 days (1 month), 2 months, 3 months, 4 months (model-dependent).
  • Qualified water volume examples: 6,000 L (2-month), 9,000 L (3-month), 12,000 L (4-month).
  • Flow rates vary by model and pressure: examples include 3.9 / 8.7 / 9.4 L/min (1 bar / 3 bar / 5 bar), 6 / 11.2 / 13 L/min, and 4.6 / 7.6 / 9.4 L/min for other variants.
  • Flow regulation: constant flow technology for sustained performance.
  • Backflow protection: integrated check valve and protective skirt for some variants.
  • Traceability: GS-1 DataMatrix on some units.
  • Regulatory: CE Class I medical device on specified models.
