Hospital water treatment system TreatOne

for healthcare facilitiesfor laboratorymicrofiltration

Overview
TreatOne and custom prefiltration skid systems are complete water quality control and prefiltration solutions specifically designed for medical and hospital environments to deliver bacteriologically controlled water (EBM) at tap points. These skid systems combine multi-stage filtration, continuous disinfection and modular design to meet strict hygiene and safety requirements for healthcare facilities.

Main functions and approach
H2O EQUIPEMENT proposes integrated, modular skid solutions that combine several complementary processes to treat and continuously monitor water quality across a looped distribution network. The systems are designed to prevent stagnation, reduce biological risk (including Legionella), and provide consistent bacteriologically controlled water adapted to sensitive environments.

TreatOne — Key features

• Multi-stage filtration: coarse pre-filters combined with intermediate meshes and an absolute terminal filter to retain particles and microorganisms.
• Typical filtration stages include: coarse 5 µm pre-filters, intermediate mesh options (1 µm and 0.5 µm), and an absolute 0.2 µm terminal filter.
• Permanent circulation loop with UVc irradiation for continuous disinfection of circulating water.
• Automated purge on remote points to prevent stagnation and maintain water quality.
• Optional proportional over-chlorination, modulated according to flow, to reinforce disinfection when required.

Advantages for healthcare facilities

• Ensures water compliant with EBM standards with a highly controlled bacteriological level.
• Significant reduction in consumable replacements (terminal filters) through the combination of filtration and daily disinfection.
• Reduced time-consuming manual maintenance and elimination of heavy procedures such as frequent thermal shocks or large-scale chlorination.
• Modular and adaptable installation that can be configured to site requirements (number of water points, volume, specific uses).

Design and implementation
Skids are custom-designed and adaptable to the specific location and site constraints. Systems are intended to be reliable and durable to protect patients and healthcare staff from water-related risks. H2O EQUIPEMENT emphasizes recognized technical expertise and tailored solutions for installation and operation in hospitals, clinics and other medical facilities.

Caractéristiques / spécifications techniques

• Brand: H2O EQUIPEMENT
• Product name / model: TreatOne
• Application: Medical and hospital water treatment, delivering bacteriologically controlled water (EBM) at tap points
• Filtration stages: coarse pre-filters (e.g. 5 µm), intermediate mesh options (1 µm / 0.5 µm), absolute terminal filter 0.2 µm
• Disinfection: permanent recirculation loop with UVc irradiation
• Anti-stagnation: automated purge on remote points
• Optional features: proportional over-chlorination proportional to flow
• Installation: modular skid systems, customizable to site constraints and number of water points
• Benefits: continuous monitoring of water quality, reduced filter consumption, lower manual maintenance effort
