Excitation light source MIK-L131

for endoscopesfor video endoscopescontinuous

Product overview
Compact fluorescence light source module designed for minimally invasive endoscopic imaging and ICG fluorescence applications in the surgical environment. Optimized for integration with surgical camera systems.

Key features

• Outlet specification (diameter): 9.0 mm – 12.0 mm
• Adjustable light source brightness (0%–100%)
• White light color temperature: 3000 K – 7000 K
• Touchscreen interaction
• CCU (camera control unit) linkage supported
• Multi-language support (optional)
• Dimensions (W × D × H): 336 × 300 × 109 mm
• Weight: 7.3 kg
• White light bulb life: approx. 30,000 h
• Fluorescence bulb life: approx. 20,000 h
• Fluorescence wavelength: 785 nm

Applications

• ICG fluorescence imaging in minimally invasive endoscopy
• Integration with surgical camera control units for real‑time fluorescence guidance

Technical specifications

• Model: MIK-L131FSA
• Outlet diameter range: 9.0 mm – 12.0 mm
• Brightness: adjustable (0%–100%)
• White light color temperature range: 3000 K – 7000 K
• Control interfaces: touchscreen, CCU linkage
• Language support: multi‑language (optional)
• Dimensions (W × D × H): 336 × 300 × 109 mm
• Weight: 7.3 kg
• White light bulb life expectancy: approx. 30,000 hours
• Fluorescence bulb life expectancy: approx. 20,000 hours
• Fluorescence wavelength: 785 nm
