Hargreaves analgesia meter 400

for animal researchfor micefor rats

(Hargreaves method) Glass stands only When large group studies are required, IITC offers either version of our glass stands to be purchased individually. Allowing users to quickly and efficiently test large study groups. Part # Description 400 Plantar test glass stand (12 mice 6 rats) non-heated 400G Plantar test (12 mice 6 rats) heated 402 Plantar Test Glass Stand (4 mice 2 rats) non-heated 402G Plantar test glass stand (12 mice 6 rats) 433 Replacement Animal Enclosure (4 mice 2 rats) 435 Replacement Animal Enclosure (12 mice 6 rats) Details The two versions available – 6 rats/12 mice 2 rats/4 mice – Supplied complete as shown with animal enclosures – Both sizes are supplied standard - Black anodized base, 5 black anodized legs. Both sizes are supplied with the standard 8” legs. Tempered glass is placed on top. The clear plexi-glas animal enclosures are placed on top of the glass and allow unobstructed views of animal subjects during testing. *Due to the fact that glass acts as a heat sink*; IITC developed the only commercially available heated glass. Warming the glass eliminates the heat sink problem, thus animals are placed onto the slightly warmed glass. Built in temperature controller in the heated base version keeps glass at a constant temperature between 30-40 deg. C which can be adjusted by user as needed. Three individual, acrylic animal enclosures are supplied. Each enclosure allows for 2 rats/4 mice allowing testing of up to 6 rats/12 mice total. Enclosures have strong magnets to prevent animals from possible escape, individual lids, clear dividers in between test subjects. - Part# 402 Glass stand - Part# 433 Animal enclosure 400(G) Heated Glass Stand Base - Footprint heated base: 30” x 13 ¾” x 4 ¼” - Footprint non-heated base: 30 ½” x 13 ¾” x ½” - Base Material: Powder coated aluminum - Heated Glass – 30 ½” x 12 ½” x 1/2” - Non-heated Glass – 30 ½” x 12 ½” x ¼” - Animal Enclosure inside dims: Mouse 4” x 4” – Rat 8” x 4” - Switchable: 110/220V - 3 Amp. - CE Certified
