Small animal veterinary CBCT scanner Planmed Verity® VET

for felinesfor caninesfor pets

Product overview
The Planmed Verity® VET is a dedicated cone beam CT (CBCT) scanner for veterinary 3D imaging of teeth, skull and extremities. It delivers submillimeter volumetric images for accurate diagnosis and treatment planning across a wide range of animal sizes and breeds, including brachycephalic animals.

Key benefits

• Accurate 3D anatomy with CBCT for assessment and treatment planning.
• Thin, sharp slices with 0.2 mm resolution for improved detection of small pathologies and fractures.
• Fast acquisition (image captured in less than a minute) reduces anaesthesia time.
• 3D visualisations facilitate communication with animal owners and support clinical decision-making.
• Mobile design suitable for animals of various shapes and sizes, including brachycephalic breeds.

Image quality
High-fidelity submillimeter 3D images enable visualisation of dental structures, cranial anatomy and peripheral bones. The scanner captures detailed datasets suitable for diagnosis, surgical planning and preoperative evaluation.

Imaging workflow and software
The system includes an intuitive graphical user interface and a dedicated workstation for image review. Data are viewed and analysed with Planmeca Romexis® veterinary imaging software. A mobile positioning table allows precise and repeatable patient positioning for efficient image acquisition.

Compact and mobile
Planmed Verity® VET is compact and easy to move, enabling flexible room layouts and bedside imaging when needed. The unit can be stored when not in use and positioned quickly to fit clinical workflows.

Data sheet (table)
Anode voltage: 80–96 kV
Anode current: 1–12 mA
Scan time: 18–35 s
Field of view, single scan: 16 x 13 cm
Field of view with stitching: 16 x 20 cm
Resolution: 0.2 mm
Power input: 100–240 V (single phase) 10–16 A (standard outlet)
Weight: 350 kg (770 lbs)

Technical specifications

• Type: Stand-alone veterinary CBCT scanner.
• Primary applications: 3D imaging of teeth, skull and extremities for diagnosis and treatment planning.
• Spatial resolution: 0.2 mm (submillimeter).
• Field of view: single 16 x 13 cm; with stitching 16 x 20 cm.
• Anode voltage range: 80–96 kV.
• Anode current range: 1–12 mA.
• Typical scan time: 18–35 s (acquisition in less than 1 minute).
• Power supply: 100–240 V single phase, 10–16 A (standard outlet).
• Unit weight: approx. 350 kg (770 lbs).
• Software compatibility: Viewing and analysis with Planmeca Romexis® veterinary imaging software (workstation included).
• Physical feature: Mobile positioning table for precise patient positioning; compact design for easy movement and storage.
