Shielded transfer hatch PASSAPREPARATI

wall-mountedwith HEPA filterlead-lined

The Shielded pass-through PASSAPREPARATI is a wall-mounted device for the shielded transfer of sensitive materials, manufactured in stainless steel and fitted with lead shielding and a ventilation unit with absolute filtration. It is engineered to ensure shielding continuity, exhaust air filtration and safety via electromechanical interlocked hatches.

Functional details

• Structure suitable for wall installation with access hatches fitted with sealing gaskets.
• Hatches equipped with low-voltage electromechanical interlock including interlock buttons and indicator lights.
• Ventilation unit complete with H14 class absolute exhaust filter and fan enclosed in a steel housing.
• Front electrical control panel included.

Technical specifications

• Commercial name: PASSAPREPARATI
• Product code: 90011
• Structure material: stainless steel AISI 304, sheet thickness 3 mm
• Shielding: lead plate, nominal thickness 5 mm (other thicknesses available: 2 mm, 3 mm)
• Air filtration: H14 absolute filter on exhaust
• Ventilation: fan enclosed in steel housing
• Access safety: hatches with gaskets and low-voltage electromechanical interlock; interlock buttons and indicator lights integrated
• Electrical panel: front-mounted panel included
• External dimensions (LxDxH): 500 x 400 x 800 mm
• Approx. internal usable dimensions: 400 x 300 x 350 mm
• Indicative weight: approx. 150 kg
