Magnetic transcranial magnetic stimulator YK-7000E

TMS + rTMSfor treatment of neurasthenia

The YK-7000E is a dual-channel, trolley-type transcranial magnetic stimulation (TMS) therapy device designed for repetitive transcranial magnetic stimulation (rTMS) to construct a three-dimensional magnetic therapy network that stimulates the central nervous system and assists nervous system rehabilitation.

Product overview
The device applies rTMS to regulate brain function via non-invasive magnetic stimulation and integrates complementary non-invasive technologies to enhance therapeutic effects.

Core technology features

• (I) TMS technology features

  • Non-invasive design: no surgery or puncture required.
  • Precise targeting: can be applied to specific areas of the cerebral cortex.
  • Gentle physical effect: controllable action process suitable for long-term clinical applications.
• (II) Simulated Bioelectric Postauricular Electrical Stimulation technology

  • Convenient postauricular targeting: electrodes attach behind the ear to precisely target the cerebellar parietal nucleus.
  • Bioelectric simulation adaptation: simulates physiological electrical signals for strong compatibility and reduced stress response in nerve tissue.
  • Adjustable parameters: supports personalized adjustment of stimulation intensity, frequency and other parameters.
• (III) Magnetic Therapy Cap technology

  • Distributed target coverage: cap integrates multiple magnetic therapy units for multi-target stimulation.
  • Flexible and comfortable ergonomic design; adjustable size to suit different head shapes.
  • Controllable magnetic field parameters: precise adjustment of magnetic field strength and duration.
  • Safe: no side effects reported in the product description.

Scope of application
Suitable as an adjunct treatment for ischemic cerebrovascular disease, neurasthenia and brain injury.

Characteristics

• Entire process non-invasive: no intracranial intervention required.
• Precise coverage of multiple targets, individually or synergistically.
• Personalized adaptation and adjustment to improve treatment outcomes.
• Safe, compatible, and without side effects; reduces neural tissue stress response.
• Synergistic effect combining electromagnetic field, bioelectricity and multi-frequency micro-vibration.
• Three complementary non-invasive technologies working together.
• Long-lasting and precise dual protection; safe, gentle and easily tolerated.
• Portable trolley design for easy movement.
• Multiple language options and CE/ISO certification noted.

Configuration

• EK-7000J / YK-7000E trolley main unit
• Smart touch screen
• Dual-channel design (allows simultaneous treatment of two patients/channels)
• Smart treatment cap — multiple models available; high-end integrated cap ergonomically designed and adjustable for different head shapes

Technical specifications

• Dual ultra-clear, low-power, wide-view LCD display with dual-channel output (simultaneous dual-channel operation).
• Treatment time adjustable from 0 to 99 minutes (step 1 minute); default start-up time 20 minutes; countdown timer with alarm.
• Magnetic therapy intensity: strong 10 mT–17 mT; weak 3 mT–9 mT.
• Magnetic field frequency: 50 Hz ±12%.
• Vibration intensity settings: off / weak / medium / strong corresponding to peak driving voltages 0 V / 10 V / 16 V / 27 V.
• Vibration frequency settings: off / weak / medium / strong corresponding to 0 Hz / 2 Hz / 5 Hz / 10 Hz.
• Deluxe ABS universal trolley for mobility.
• High-end integrated aviation treatment cap, ergonomically designed, comfortable to wear and size-adjustable.
