DIMENSION: mm 820 x 640 x 1600 H
CONSTRUCTION: solid, sturdy, made of technopolymer and epoxy powder - coated steel to obtain maximum lightness and maneuverability.
DESIGN: accurate to the smallest detail.
STRUCTURE: self - supporting, monocoque body.
TOP: wide work top with rims in technopolymer without sharp edges to make it easy to clean and disinfect.
Height from ground: mm 1000
PUSH HANDLE: ergonomic, integrated on structure
FRONT SIDE: it is pre - set to house a central locking system and modular drawers.
Drawers are entirely made in technopolymer, with no sharp edges and rounded interior.
They slide silently thanks to their ball bearing rails . They are equipped with end stoppers and are pre - set for central locking system.
DEFIBRILLATOR HOLDER: Plexiglas tray (dim. mm 390 x 320 x 20 H) and stainless steel arm, 360 rotation and lockable every 10.
Supplied with two safety straps.
I.V. POLE: made of stainless steel, height - adjustable.
CPR MASSAGE BOARD: made of transparent Plexiglas and placed in front of the trolley . STANDARD DRAWERS: entirely realized in technopolymer:
no. 3 drawers dimensions mm 600 x 475 x 137 H;
no. 1 drawer dimensions mm 600 x 475 x 274 H .
LOCKING SYSTEM: seal locking system; no. 20 plastic disposable seals (cod. 617363 ) supplied with the trolley
LEFT SIDE: additional, pull out work surface in technopolymer; built - in compartment, complete with four shelves with rim entirely made of technopolymer.
RIGHT SIDE: built - in compartment in plastic; no. 1 waste bin; no. 1 catheter or probe holder, no. 1 small shelf with rim entirely made of technopolymer.
