Cryogenic freezer CRF-200

for vaccinesfor laboratoryfor biobanks

Overview
Labotemp CRF-200 cryogenic freezer provides stable ultra-low temperature storage from -105°C to -135°C for long-term preservation of temperature-sensitive biological and clinical samples. The 118 L inner chamber is manufactured in 304 stainless steel and the cabinet features a 150 mm foamed insulation layer to minimise thermal ingress and maintain uniform temperature distribution.

Design & Operation
The unit uses a single-compressor refrigeration system with an eco-friendly fluorine-free refrigerant. Electronic temperature control with a PTC probe and digital display allows precise setpoint management. Audible and visual alarms and a powder-coated steel exterior support safe continuous operation in laboratory and medical environments. High-efficiency EBM condenser fans and a SECOP (DANFOSS) compressor ensure reliable cooling performance.

Key advantages

• Stable cryogenic storage across adjustable range -105°C to -135°C for biological and clinical specimens
• Precise electronic temperature management with PTC probe and digital display
• Environmentally considerate refrigerant and efficient compressor design to reduce power draw
• Laboratory-grade construction: 304 stainless steel interior and robust insulation for sample integrity

Key Features

• Fluorine-free environmental protection refrigerant
• High-efficiency SECOP (DANFOSS) compressor
• 150 mm foaming layer for reduced thermal loss
• 118 L inner chamber in Stainless Steel 304
• German EBM condenser fans
• Electronic temperature control, digital display, PTC probe, audible and visual alarms

Applications

• Designed for laboratories, biomedical research centres, cryogenic storage facilities and pharmaceutical institutions for long-term preservation of cell cultures, vaccines, enzymes and other ultra-low temperature materials

Technical specifications

• Model: CRF-200
• Capacity: 118 L
• Temperature adjust range: -105°C to -135°C, adjustable
• Compressor: SECOP (DANFOSS)
• Voltage: 220 V 50/60 Hz
• Alarm: Audible and visual alarm
• Input Power: 1020 W
• Power consumption: 19.5 kW·h/24h
• Refrigerant: Fluorine-free environmental protection refrigerant
• Temperature control: Electronic temperature control
• Protect grade: I/B
• Climate type: N
• Refrigeration system: Single-compressor refrigeration system
• Temperature display: Digital data display
• Probe: PTC
• Condenser fans: EBM
• Exterior material: Powder coated steel plate
• Interior material: Stainless Steel 304
• Liner: Stainless Steel 304
• Thickness of foaming layer: 150 mm
• Balance hole: 1 (Diameter 18 mm)
• Castors: 4
• Net weight / Gross weight: 135 / 175 kg
• External dimensions: 1270 × 795 × 990 mm
• Internal dimensions: 540 × 400 × 560 mm
• Package size: 1340 × 865 × 1180 mm
