Laboratory freezer LDF-02

for vaccinesfor hospitalsfor sample storage

Product overview
Labotemp Laboratory Freezer LDF-02 is a 58L vertical ultra‑low temperature freezer designed for controlled storage of laboratory and clinical samples. The unit offers an adjustable temperature range from -10°C to -40°C, electronic temperature control and a 304 stainless steel interior, providing hygienic and stable conditions for vaccines, reagents and biological specimens in diagnostic, research and medical environments.

Why choose Labotemp LDF-02?

• Space-efficient 58L vertical footprint suitable for benchtop or under-counter installation
• Adjustable -10°C to -40°C range for diverse sample preservation needs
• Continuous-operation design with audible and visual alarms for sample protection

Key features

• Fluorine‑free environmental refrigerant
• Slim under-counter compatible vertical design
• Advanced electronic temperature control for stable setpoint maintenance
• Audible and visual alarm system for over-temperature and fault alerts
• Compact vertical configuration for space-conscious laboratory or medical setups

Applications

• Storage of vaccines, reagents, biological samples and other temperature-sensitive materials requiring preservation down to -40°C in laboratories, hospitals and research institutions

Technical specifications

• Model: LDF-02
• Capacity: 58L
• Temperature range: -10 ~ -40°C, adjustable
• Voltage: 220V/50Hz
• Alarm: Audible and visual alarm
• Input power: 300W
• Power consumption: 3.4 kW·h/24h
• Protection grade: I/B
• Refrigerant: Fluorine‑free environmental refrigerant
• Temperature control: Electronic temperature control
• Gross weight: 98 kg
• External dimensions: 670 × 765 × 1025 mm
• Internal dimensions: 410 × 410 × 385 mm
• Package size: 840 × 740 × 1105 mm
