DNA gel documentation system GEL21-128

for RNAfor proteinswith CCD camera

Product Details
Gel instrument is a technique used in laboratory to separate charged molecules like DNA, RNA and proteins according to their size. Gel electrophoresis instruments are commonly used to run and compare DNA samples.

• Used in Forensic, molecular biology, genetics, microbiology labs, gel electrophoresis instruments
• Also known as Laboratory Gel instrument

Key Features

• The zoom, focus, aperture, UV light and white light can be controlled by PC.
• Auto-delay-shutdown function for UV light.
• 6x zoom lens, easy to observe the zooming of gel.
• The zoom, focus, aperture, UV light and white light can be controlled by PC.

Features

• The zoom, focus, aperture, UV light and white light can be controlled by PC.
• Auto-delay-shutdown function for UV light.
• 6x zoom lens, easy to observe the zooming of gel.
• The zoom, focus, aperture, UV light and white light can be controlled by PC.
• Effective pixel 1280x1024

Specifications
Effective pixel: 1280x1024
Pixel density: 10 bit
Pixel size: 5.4x5.4 (um)
Resolution: 1.4 megapixels
Signal to noise ratio: ≥56db
Sensitivity: Can detect the double chain DNA of EB staining below 20pg
Camera: Low illumination and high resolution digital CCD
Zoom lens: F=1:1.2, 2/3" inch 6x zoom lens
Filter: 590 (nm)
UV light transmission size(WxL): 250x200 mm
Visible light transmission size(WxL): 250x210 mm
Transmission UV wavelength: 302 nm
Reflectance UV wavelength: 254, 365 nm
Transmission UV lamp power: 302nm (8W)
Reflectance UVlamp power: 254nm (11W), 365nm (11W)
Dimension (LxWxH): 470x405x820 mm
Weight: 29.0 kg

Technical Specifications / Characteristics

• Effective pixel: 1280x1024
• Pixel density: 10 bit
• Pixel size: 5.4x5.4 (um)
• Resolution: 1.4 megapixels
• Signal to noise ratio: ≥56db
• Sensitivity: Can detect the double chain DNA of EB staining below 20pg
• Camera: Low illumination and high resolution digital CCD
• Zoom lens: F=1:1.2, 2/3" inch 6x zoom lens
• Filter: 590 (nm)
• UV light transmission size(WxL): 250x200 mm
• Visible light transmission size(WxL): 250x210 mm
• Transmission UV wavelength: 302 nm
• Reflectance UV wavelength: 254, 365 nm
• Transmission UV lamp power: 302nm (8W)
• Reflectance UVlamp power: 254nm (11W), 365nm (11W)
• Dimension (LxWxH): 470x405x820 mm
• Weight: 29.0 kg
