Drying oven C860M

heatingsterilizationheat treatment

The C860M Integrated Residue-on-Ignition Testing System is a compact, automated instrument based on the gravimetric method for determination of residue on ignition and ash content. It is designed for use with pharmaceuticals, pharmaceutical packaging materials, foods, food contact materials (FCMs) and chemical reagents and complies with relevant pharmacopoeia and food/chemical test standards.

Characteristics

• Traceable Data — Equipped with Labthink's fully automatic gripper for rapid transfer and weighing of 16 test cups; dual-separate-chamber design isolates ignition and weighing to avoid high temperature/humidity influence on the balance; optional Germany-imported touch electronic balance with repeatability up to 0.05 mg; visual, traceable balance design and quickly removable self-calibration weight for convenient verification.
• Safe & Compliant — Integrated muffle furnace, desiccator and analytical balance in one system; full testing sequence meets relevant standards; rapid liquid cooling enables true room-temperature weighing; independent electrical control ensures safe operation.
• Intelligent Control — 10.1" medical-level touch screen for standalone operation; desktop footprint saves space; automatic sequence for ignition, drying, cooling and room-temperature weighing; multi-sensor alerts with audible/visual reminders; network port for remote control and firmware upgrades; professional software supporting GMP traceability, multi-level user rights and configurable permissions; optional electronic signature per 21 CFR Part 11.

Testing Principles

• Weigh an appropriate sample (typically 1.0–2.0 g) into a crucible ignited to constant weight, recordWeight, gently carbonize if required, add 0.5–1 mL sulfuric acid when specified, evaporate volatiles then ignite at 700–800°C to constant weight; final mass difference corresponds to residue on ignition (ash content).

Test Standard Compliance

• Designed to meet pharmacopoeia requirements and standards such as YBB00012002-2015, YBB00342002-2015, YBB00262005-2015 for pharmaceutical production and packaging.
• Supports GB/T 5009.4, GB 31604.6 and related standards for food and food contact materials.
• Supports GB/T 9741 and related standards for residue-on-ignition determination of chemical reagents.

Applications

• Basic applications — Pharmaceuticals: residue on ignition and ash content determination for APIs and formulation materials.
• Extended applications — Pharmaceutical packaging: composite films, bags, bottles, rubber stoppers and caps; Foods: ash content of various food matrices; Food contact materials: residue on ignition of FCMs; Chemical reagents: ash/residue testing of reagents.

Specifications

• Model: C860M
• Test range: 0.3–160000 mg (standard); optional 0.05–50000 mg
• Resolution: 0.1 mg (standard); optional 0.01 mg
• Repeatability: ±0.3 mg (standard); optional ±0.05 mg
• Temperature range: Room temperature to 800 °C
• Temperature fluctuation: ±25 °C
• Optional functions: 21 CFR Part 11 (optional); GMP computer system requirements (optional)
• Test stations: 16
• Test cup volume: 25 mL (customizable; test range may depend on delivery)
• Gas specifications: Compressed air (user-supplied)
• Gas source pressure: ≥ 72.5 PSI / 500 kPa
• Port size: Φ8 mm polyurethane tube
• Instrument dimensions: 24.8” H x 41.3” W x 28.7” D (63 cm × 105 cm × 73 cm)
• Power supply: 120 VAC ±10% 60 Hz or 220 VAC ±10% 50 Hz (select)
• Net weight: 396 lbs (180 kg)
• Standard configuration: Instrument host, balance (0.1 mg), liquid cooling module, 16 test cups, Φ8 mm polyurethane tube
• Optional parts: Software, GMP computer system, 21 CFR Part 11, air compressor, 25 mL test cups, balance (0.01 mg), weight (50 g)
