Ophthalmic examination chair OC-1electricheight-adjustablewith legrest
Add to favorites
Compare this product
Characteristics
- Applications
- ophthalmic
- Operation
- electric
- Features
- height-adjustable, with legrest, on casters
- Height
Min.: 835 mm
(32.9 in)Max.: 1,110 mm
(43.7 in)- Width
Min.: 885 mm
(34.8 in)Max.: 1,015 mm
(40 in)
Description
Short description
Ergonomic design and stable support for ophthalmic surgeons. OC-1 combines an electrically adjustable seat with manual backrest and armrest adjustments and an integrated battery pack for mobile/backup use up to 20 hours.
Product overview
Dimensions
Width: 885 – 1 015mm
Depth: 740mm
Height: 835 – 1 110mm
Technical specification
Available colours
Multiple upholstery and colour options available; see product page for combinations and materials.
Files
Technical and product files (PDF) available for download on the product page.
Key features
Ergonomic design and stable support for ophthalmic surgeons. OC-1 combines an electrically adjustable seat with manual backrest and armrest adjustments and an integrated battery pack for mobile/backup use up to 20 hours.
Product overview
- Intended for ophthalmic surgeons during cataract surgery and other procedures requiring seated support and mobility around the operating field.
- Electrically elevated seat with ergonomically positioned foot switch for smooth upward/downward movement.
- Manually adjustable backrest and armrests to allow optimal surgeon posture and patient access.
- Robust base with three heavy-duty castors for stable movement and positioning in the operating theatre.
- Foot-operated main brake and manual locking system for secure immobilization.
- Removable battery pack (24V, 2.2Ah) for mobile operation or backup power; charging specifications included.
- Marked as a medical device; use in accordance with the instructions for use and local regulations.
Dimensions
Width: 885 – 1 015mm
Depth: 740mm
Height: 835 – 1 110mm
Technical specification
- Height adjustment range: 550 – 750mm
- Arm supports rotation range: up to 126°
- Armrest height adjustment: 78mm
- Backrest height adjustment: 75mm
- Backrest forward/backward adjustment: 55mm
- Input: 100-240V AC, 50/60Hz
- Battery pack: 24V, 2.2Ah; battery charging: 24V ±0.5V, 1.2A; working time: up to 20h
- Packaging: 1 pallet, 120x80x160cm, approx. 85kg (gross)
Available colours
Multiple upholstery and colour options available; see product page for combinations and materials.
Files
Technical and product files (PDF) available for download on the product page.
Key features
- Model: OC-1 ophthalmic operator’s chair
- Electrically elevated seat with foot switch for height adjustment
- Manual backrest and armrest adjustments for posture optimization
- Three heavy-duty castors, foot-operated brake and manual locking system
- Battery pack 24V, 2.2Ah — mobile operation and backup up to 20 hours
- Power input: 100-240V AC, 50/60Hz
- Dimensions (W×D×H): 885–1 015mm × 740mm × 835–1 110mm
