Digital mobile radiography unit MasteRad® MX Go

portable

Overview
The MasteRad MX Go is a portable, battery-powered mobile X-ray system that integrates a compact generator with an adjustable trolley for on-site radiography where mains power is not available.

Key features

• 100% wireless operation with strong WiFi connectivity
• Built‑in battery: up to 400 exposures per full charge
• Lightweight system design: 85 lb with generator (approx. 38.6 kg)
• Compact when folded: 53” L x 22” W x 26” H
• Durable multi-terrain solid rubber wheels and 3” swivel casters
• 14” wheels for stable transport; single-lever wheel action
• Integrated laptop holder with cable management
• Gas-spring assisted extension for smooth setup
• Optional winch hook pull top strap for load handling

Generator specifications

• Input power: Built-in battery with AC charger
• Working frequency: ≥ 50 kHz
• Maximum output: 3.2 kW
• Tube voltage: 40 kV – 125 kV
• Tube current: 25 mA (40–60 kV) / 20 mA (61–100 kV)
• Exposure time range: 0.4–50 mAs (22 steps)
• Total filtration: 3 mm Al; collimator included (continuous with center indicator)
• Focal spot: fractional focal
• Generator dimensions (L×W×H): 522 × 227 × 217 mm (20.5” × 9” × 8.5”); weight: 12 kg (26.45 lb)

Acquisition & connectivity

• Simple user interface optimized for quick exams
• 100% battery supported — no external mains required during operation
• Wireless workflow enabled by robust WiFi link

Trolley

• Height: 2250 mm / 88.5 inches
• Weight: 56 lb (approx. 25.4 kg)
• Material: USA-made aluminum; surface: chrome / powder coated
• Wheels: 14” solid rubber with 3” swivel casters
• Wheel action: single-movement control with one lever
• Optional winch hook pull top strap

Laptop support

• 14” wide holder plate with two positions for ergonomic placement
• Integrated AC power cord holder for neat cable management

Operation & safety

• Generator rotation: 360° around X/Z axis for flexible positioning
• Ease of use: gas spring assist and locking lever action
• Safety features: yoke safety strap, locking pins, exposure switch holder bracket and support rail for easy loading
