Inspection camera head WACAM Eco-HD

digitalfull HD1920 x 1080

Product overview
Wacam Eco HD is a compact high-definition inspection camera head designed for industrial visual inspection and documentation. It delivers Full HD imaging, fast shutter speeds and configurable user presets for field use.

Camera Head

• Aspect ratio: 16:9
• Image sensor: 1/3” MOS
• Immersible (using the attached cap)
• Weight: approx. 150 g
• Diameter: 36.5 mm
• Length: 65.2 mm (without grommet)

Features

• Automatic white balance and boost function
• On-screen menu (multilingual)
• 3 user settings storable for quick configuration
• 2.5x digital zoom
• Freeze function for frame capture
• Built-in character generator for image annotations

Video system

• Image resolution: Full HD 1920 x 1080
• TV resolution: > 900 lines
• Sensitivity: < 3 lux (1/1.4)
• White balance: automatic, with data hold
• Shutter speed: 1/50 (1/60) to 1/10,000 sec

Video out terminal

• 1 x HDMI

Other connections

• 1 x USB (A) (USB-keyboard)
• 1 x Remote IN (footswitch)
• 1 x Remote OUT (video printer, video recorder, ...)
• 1 x RJ45 (Service)

Technical specifications

• High-definition camera head (1-MOS)
• Full HD resolution (1920 x 1080)
• High speed shutter for motion capture
• Multilingual on-screen menu and 3 user presets
• Aspect ratio 16:9; Image sensor: 1/3” MOS
• Immersible with attached cap; Weight approx. 150 g; Diameter 36.5 mm; Length 65.2 mm (without grommet)
• 2.5x digital zoom; Freeze function; Character generator
• Sensitivity < 3 lux (1/1.4); TV resolution > 900 lines; Shutter speed 1/50 (1/60) to 1/10,000 sec
• Video out: 1 x HDMI
• Interfaces: USB-A, Remote IN, Remote OUT, RJ45 (Service)
