Medical ECG cable

monitoringbanana plug10-wire

Overview
This Converter Kit adapts ECG cables with banana-plug connectors from legacy machines to the QHeart® Sensor, enabling fast and accurate 12-lead ECG acquisition across device brands.

Key benefits

• Save up to 70% time in lead setup
• Simple, plug-and-play connection
• Error-proof lead mapping
• Accurate electrode placement for reliable signals
• High-quality 12-lead ECG recordings
• Improved sanitary handling compared with manual lead placement

How it works
Insert the 10 banana-plug connectors from a standard 12-lead ECG cable into the corresponding inputs on the Converter Kit. Then connect the Converter Kit to the QHeart® Sensor using the supplied extension cable to perform rapid, reproducible lead placement and recording.

Compatible devices
Compatible with all ECG machines that use multi-lead cables terminated with banana-plug connectors; no modification of the host device is required.

Embedded video
The product page includes an embedded demonstration video illustrating setup, connection to the QHeart® Sensor and sample 12-lead recordings.

FAQ highlights

• Primary purpose: enables connection of legacy banana-plug ECG systems to the QHeart® Sensor for streamlined 12-lead acquisition.
• Operation note: after plugging banana connectors into the Converter Kit, use the extension cable to link the Converter Kit to the QHeart® Sensor and proceed with lead placement and recording.

Specifications

• Product name: Converter Kit
• Compatibility: all ECG machines using banana-plug multi-lead cables
• Connectors: 10 banana-plug inputs for standard 12-lead cables
• Function: adapts banana-plug ECG cables to QHeart® Sensor via extension cable for high-quality 12-lead ECG
• Main benefits: time saving (up to 70%), simplified workflow, error-proof lead placement, improved sanitary handling, accurate, high-quality ECG signals
• Media: product page includes embedded demonstration video
