Dental induction casting machine RETOCAST I

centrifuge

Description
The RETOCAST I is a centrifugal casting machine designed for dental laboratories to cast noble metals, non-precious alloys and model castings. It features an adjustable induction melting generator and a droppable induction coil for safe and efficient casting. The electronic lid lock, timer and emergency stop ensure operator safety while the large sight glass and intuitive control panel simplify process monitoring and use.

Technical features

• Induction heating with variable power
• Sight glass for optical temperature monitoring
• Compatible with graphite or ceramic crucibles
• Droppable induction coil (drops at casting)
• Electronic lid lock, timer and emergency stop
• Three selectable starting speeds
• Line voltage: 230 V / 50–60 Hz
• Power consumption: 3,200 W
• Compressed air: 6 bar required, consumption 5 l/min
• Dimensions (H/W/D): 530(930) / 740 / 510 mm
• Weight: 60 kg
• Operating speed: 500 rpm
• Casting ring compatibility: sizes 1–9 and model casting
• Max. metal quantity: noble metal 110 g; non-precious metal 55 g
• Min. metal quantity: non-precious metal 15 g
• Housing: stainless steel
• Order number: 18000000

Characteristics / specifications

• Model: RETOCAST I
• Application: casting of dental restorations from noble and non-precious metals and model castings
• Heating method: induction melting, stepless power control
• Temperature control: visual control via sight glass
• Crucibles: graphite or ceramic crucibles compatible
• Coil: droppable induction coil for casting
• Safety: electronic lid lock, timer and emergency stop
• Drive / power: 3,200 W, 230 V / 50–60 Hz
• Compressed air: 6 bar required, consumption 5 l/min
• Dimensions (H/W/D): 530(930) / 740 / 510 mm
• Weight: 60 kg
• Speed: 500 rpm
• Casting ring sizes: 1–9 and model casting
• Metal quantities: max noble metal 110 g / max non-precious metal 55 g; min non-precious metal 15 g
• Housing material: stainless steel
• Order number: 18000000
