Application. For the room of the uterus cervix pathology.
The optical system. Apochromatic optics with multilayer antireflex coating.All lenses and prisms are made of glass of the highest quality, produced by German company “SCHOTT”. A wideangle eyepieces 12,5X with the increased removal of the exit pupil.
Illumination. Super bright led of 10 W is integrated in the optical head of the colposcope.The five-lens condenser forms spot of light with the illumination of more than 60 000 Lux. with perfect uniformity over the entire area
The optical head. Ergonomic handles switching magnification, fine focus knob, handle smooth change of interpupillary distance, conveniently located plate O green filter button for kolposnimkov. Equipped with special holes to allow mounting of attachments.
Tripod. Compact, robust. Equipped with a spring arm pantograph and self-directed rubberized wheels with breaking system. Axis on needle bearings and bearing. Friction handle levers for fixing and the optical head in position. Possibility of delivery with fastening to a chair.
Functions: button for the receiving of colposcopic pictures. Handle of the fine focusing, ergonomic handles of switching of the magnification, the plate of input-output of green light diode is located conveniently,a handle of a smooth variation of interpupillary distance,locking lever breaks all the rotation axes of the colposcope simultaneously which allows fixing the optical head quickly to prevent the random displacement, fixation of diopter ring of eyepiece, handle of smooth adjustment of light intensity.
