Medical trolley D 1408/350

hospitaltransportstorage

Standard mobile-bottom trolley compliant with the RABC method, designed to improve worker ergonomics by ensuring a constant working height and adjustable bottom resistance.

Main features

• Product compliant with the RABC method.
• Bottom resistance adjustable from 20 to 100 kg in 10 kg increments (standard setting at delivery: 50 kg).
• Construction in anodized aluminum alloy: durable, corrosion-resistant and lightweight.
• Ergonomic mobile bottom allows the operator to work at a constant height.
• Robust, reliable, maintenance-free operating system.
• Resistance adjustment via opening of the enclosure on the short side of the trolley to remove or add springs.
• Circular bumper at the upper edge.
• Two fixed and two swivel wheels Ø 125 mm, fitted with ball bearings and wire guards.

Designations and specifications by model

• D 1408/180 — Reference: 375.027D — Overall dimensions: L.855 x D.550 x H.760 mm — Usable dimensions: L.740 x D.510 x H.485 mm — Volume: 180 L — Spring tensions: 20 kg + 3×8 kg.
• D 1408/350 — Reference: 375.027 — Overall dimensions: L.1115 x D.690 x H.855 mm — Usable dimensions: L.1000 x D.650 x H.580 mm — Volume: 380 L — Spring tensions: 50 kg.
• D 5408/580 — Reference: 375.028 — Overall dimensions: L.1515 x D.740 x H.905 mm — Usable dimensions: L.1400 x D.700 x H.620 mm — Volume: 615 L — Spring tensions: 50 kg.

Options

• Aluminum clamp to secure two trolleys together.
• Braked wheels Ø 125 mm.
• Optional handle.
• Springs supplied in increments of approximately 8 kg (allowing adjustment of the return bottom).

Technical characteristics / specifications

• Material: anodized aluminum alloy (corrosion-resistant).
• Bottom resistance adjustment: 20–100 kg, in 10 kg steps (standard 50 kg at delivery).
• Adjustment principle: add/remove springs via side enclosure.
• Wheels: 2 fixed + 2 swivel Ø 125 mm, ball bearings, wire guards, optional brakes.
• Bumper: circular at upper edge for protection.
• System: robust, reliable and maintenance-free construction.
• Available volumes and dimensions: 180 L / 380 L / 615 L (see designations above for usable and overall dimensions).
