Oxygen therapy hyperbaric cabin HBO-DR250

multiplace

Overview
The HBO-DR250 is a multi-person hyperbaric oxygen chamber built with aerospace-grade T700 carbon fiber. Designed for clinical and premium wellness environments, the unit supports customizable pressurization to 2.5 ATA and integrates an air compressor, oxygen concentrator and cooling unit controlled via a touch digital panel.

Key Details

• Model: HBO-DR250
• Capacity: 2–4 persons
• Chamber size: L2216 × W1615 × H2096 mm
• Chamber weight: 1300 kg; Host size: L560 × W1010 × H1280 mm; Host weight: 225 kg
• Pressure: 2.5 ATA (customizable)
• Oxygen concentration: 90 ± 3%
• Voltage: 220V 50Hz (customizable); Power: 4.5 kW

Main Features

• Aerospace-grade T700 carbon fiber construction for high strength-to-weight ratio
• Integrated system including air compressor, oxygen concentrator and cooler
• Touchscreen digital control panel with intelligent control modes
• Multiple safety protections and manual/automatic valves
• Installation-free design for rapid on-site setup
• Customizable pressure settings and external appearance options

Therapeutic Benefits

• Supports collateral angiogenesis and improved tissue oxygenation
• Maintains a low-bacterial environment and supports immune response
• Helps regulate inflammation and HIF pathway activity
• Supports collagen synthesis for improved skin elasticity
• Aids post-exercise recovery and enhances antioxidant capacity
• May help relieve altitude-related symptoms, improve sleep quality and reduce fatigue
• Provides rapid intervention potential for acute conditions such as intoxication

Specification Table
Model: HBO-DR250
Pressure Optional: 2.5 ATA (customizable)
Material: T700 Carbon Fiber
Chamber Size: L2216 × W1615 × H2096 mm
Chamber Weight: 1300 kg
Host Size: L560 × W1010 × H1280 mm
Host Weight: 225 kg
Oxygen Concentration: 90 ± 3%
Voltage: 220V 50Hz (customizable)
Power: 4.5 kW
Control Panel: Touch digital display
Certification: CE
Payment: T/T, L/C
Customizable color and appearance

Notes
Intended for multi-person clinical or premium wellness settings. Pressure, voltage and cosmetic options can be customized to client requirements.
