Ophthalmic operating table TY

ophthalmic operating table
ophthalmic operating table
ophthalmic operating table
ophthalmic operating table
ophthalmic operating table
Add to favorites
Compare this product


ophthalmic, universal, veterinary, gynecological, cardiovascular, orthopedic, emergency, for animal research, ENT, urological, for maxillary surgery, cardiology, neurosurgery, laparoscopic, radiology, dermatology, maxillofacial surgery, endoscopy
Patient type
for large animals
height-adjustable, on casters, tilting, X-ray transparent, ergonomic, rotating


★Description The frame, column and base are stainless steel, easy to clean and corrosion resistant. The mechanical operating table is raised and lowered with a pedal oil pump, which runs smoothly and is safe and reliable. All other movements are operated by mechanical gears. ★ Feature 1.Rotation Function The manual operating table can be rotated 360°, doctors can adjust the angle according to their posture during surgery, which greatly increases the operating space during surgery. (Optional) 2.Quick Switch to Flex Position The operating table requires a 200° protrusion (flexion) on the table surface at one time by operating the handle, which can be used to replace the lumbar bridge function. 3.Double Layer Tabletop The tabletop requires double-layer composite tabletop, low X-ray absorption coefficient and high-definition perspective effect. ★Parameters Length and Width - 2020mm*500mm Elevation( Up and Down) - 1010mm/ 760mm Head Plate (Up and Down) - 45°/70° Back Plate (Up and Down) - 75°/ 15° Leg Plate (Up /Down/ Outward) - 15°/ 90°/ 90° Trendelenburg/Reverse Trendelenburg - 25°/ 25° Lateral Tilt (Left and Right) - 20°/ 20° Kidney Bridge Elevation - ≥110mm Mattress - Memory Mattress Main Material - 304 Stainless Steel Maximum Load Capacity - 200 KG Warranty - 1 Year Standard Accessories 1 - Anesthesia Screen - 1 Piece 2 - Body Support - 1 Pair 3 - Arm Support - - 1 Pair 4 - Shoulder Rest - 1 Pair 5 - Knee Crutch - 1 Pair 6 - Fixing Clamp - 1 Set 7 - Mattress - 1 Set
