CT scan contrast media injector YSW6800

for angiographytriple-head

Product
YSW6800 CT contrast injection system for automated contrast delivery in CT imaging

Advantages

• Save time
  • Three-way tubing (two contrast channels, one saline channel) for rapid switching
  • Alpha Assistant automates tubing connection and air venting to reduce patient changeover time
• Reduce operating costs
  • Reusable pump tubing lowers consumable cost versus syringe-based injectors
  • Faster contrast switching increases daily patient throughput and contrast utilization
• User-oriented operation
  • 7-inch and 15-inch touchscreens for main and on-body operation
  • Support for up to 12 programmable injection phases
  • Magnetic docking with 90° rotatable bottle holder for quick bottle replacement without latches
  • MixFlow algorithm for mixed-flow injection optimized for high-clarity CT angiography

Features

• Three-channel design (dual contrast channels + saline)
• Minimal, serviceable exterior with rolling-pump mechanism
• 7-inch and 15-inch touchscreens
• Up to 12 injection phases and program storage
• Rolling pump supporting reusable tubing
• Alpha Assistant for automated tubing connection, priming and air removal

Technical specifications
YSW6800 CT Contrast Injector — Technical specifications

• Model: YSW6800
• Main controller power: AC 198–242 V, 50 ±1 Hz, 980 VA
• Channels: Three-channel
• Maximum injection pressure: 330 psi
• Flow rate: 0.1–10 mL/s (0.1 mL/s increment)
• Dual-flow mixing ratio: 5%–95%
• Injection phases: Up to 12
• Alpha Assistant: automatic inner/outer tubing connection, automatic air removal and priming; detects outer tubing presence
• Overpressure protection: user-selectable (pressure reduction then stop or immediate stop)
• Air detection alarm: supported (5 ultrasonic sensors)
• Automatic left/right channel switching and inner tube up/down movement: supported
• Main screen: 15-inch touchscreen; on-body screen: 7-inch touchscreen (splash-proof)
• Program storage: up to 2,000 protocols
• Remaining volume display: real-time display and automatic refresh on bottle change
• Injection/venting: direct bottle connection; no syringe or bottle opening required; automatic air removal
• Magnetic bottle holder: 90° rotation for easier removal without latches
• Heating sleeve: optional aluminum alloy heating sleeve
• Data transmission: wired or optional wireless
• KVO (Keep Vein Open): supported
• Injection delay / inter-phase delay: 0–1000 s
• Timer: supports start-triggered and end-triggered timing
• Test injection from on-body touchscreen: supported
• One-touch automatic preparation: supported
• Medication change detection: three-channel sensing
• Information workstation: not supported
