PVC orogastric tube SMD 602

graduatedradiopaque

Product name
Levin's Tube / Stomach Tube

Short code
SMD 602

Key features

• Intended for gastro-intestinal (stomach) drainage
• Manufactured from non-toxic, medical-grade PVC
• Coned distal end with four lateral eyes for efficient drainage
• Proximal universal funnel connector for standard fittings
• Markings at 45, 55, 65 and 75 cm and radiopaque line for accurate placement

Packaging

• Sterile, individually packed in peelable pouch
• Box of 50; Master carton of 500 (6 to 14 FG)
• Box of 50; Master carton of 600 (16 to 20 FG)

Packing & Weights / Carton Dimensions
Gross: 16.5 kg (14 FG)
6 to 14 FG – 790 x 480 x 280 mm
16 to 20 FG – 680 x 480 x 520 mm

Sizes
EFFECTIVE LENGTH — 122 cm
TOTAL LENGTH — 125 cm

Available sizes (FG) and colour codes

• 6 FG — Green
• 8 FG — Blue
• 10 FG — Black
• 12 FG — White
• 14 FG — Green
• 16 FG — Orange
• 18 FG — Red
• 20 FG — Yellow

Technical specifications

• Intended use: Gastro-intestinal drainage
• Material: Non-toxic, medical-grade PVC
• Distal design: Coned distal end with four lateral eyes for efficient drainage
• Proximal connector: Universal funnel connector
• Placement aids: Markings at 45, 55, 65 and 75 cm and radiopaque line for accurate placement
• Effective length: 122 cm
• Total length: 125 cm
• Available French Gauge (FG) sizes: 6, 8, 10, 12, 14, 16, 18, 20
• Colour coding provided per FG for identification
• Sterility: Sterile, individually packed in peelable pouch
• Standard packaging: Box of 50; Master cartons as specified above
• Gross weight example: 16.5 kg for 14 FG packing configuration
• Carton dimensions vary by FG range as specified above
