Vascular access sheath AXS Infinity LS® Plus

hydrophilic

Overview
The AXS Infinity LS® Plus Long Sheath is designed to provide extended distal support and improved access for neurovascular interventions. Bench testing is not necessarily indicative of clinical performance. Data on file.

Features and benefits

• Additional lumen clearance to permit contrast injections and simultaneous use of multiple devices
• Large 0.091 in lumen specifically sized to accommodate the AXS Vecta 74 aspiration catheter

Take it higher for support
Long, soft distal flex zone enables the sheath to track further into distal vasculature to provide support during device delivery.

Durable with Pro Technology™
Dual-layer polymer jacket combined with a stainless-steel coil provides structural robustness while maintaining an 8F / 0.109 in outer diameter.

Distal shaft
Long, soft distal flex zone with a 14.5 cm cross-coil flex segment designed to negotiate tight turns down to 2.2 mm.

Pro Technology™ proximal shaft
Dual-layer polymer jacket with stainless-steel coil for proximal robustness and trackability.

Design specifications
ID | OD | Lengths
0.091 in (2.31 mm) | 8F (0.109 in; 2.77 mm) | 70 cm, 80 cm, 90 cm

Technical features

• Soft 14.5 cm cross-coil flex segment allows tight turns to 2.2 mm
• 10 cm hydrophilic coating for improved trackability and arch stability
• Pro Technology™ dual-layer polymer jacket with stainless-steel coil provides robustness while maintaining 8F / 0.109 in OD
• ID: 0.091 in (2.31 mm)
• OD: 8F (0.109 in; 2.77 mm)
• Available lengths: 70 cm, 80 cm, 90 cm
